international harvester 1206
 | 1965 - 1967 | 1965 - 1967 |
|---|---|---|
1965 - 1967 | ||
1965 - 1967 |
|---|
Production | |
|---|---|
Manufacturer | International Harvester |
Built in Rock Island, Illinois, USA | |
Total built | 1,289 |
Original price was $9,450 in 1967 | |
Variants | |
|---|---|
IH 1206 | standard front |
Farmall 1206 | row-crop |
Wheatland | larger platform, heavy drawbar |
International Harvester 1206 Engine | |
|---|---|
International Harvester 5.9L 6-cyl diesel | |
Fuel tank | 35 gal
132.5 L |
Engine details ...  | |
International Harvester 1206 Transmissions | |
|---|---|
8-speed unsynchronized | |
16-speed partial power shift | |
Transmission details ...  |
International Harvester 1206 Power | |
|---|---|
Drawbar (claimed) | 99.6 hp
74.3 kW |
PTO (claimed) | 112.6 hp
84.0 kW |
Drawbar (tested) | 95.00 hp
70.8 kW |
PTO (tested) | 112.64 hp
84.0 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Differential hydraulic dry disc brakes | |
Open operator station. Optional one-door cab. Optional heat and air-conditioning. |
Photos | |
|---|---|
 | |
International Harvester 1206 photos...  |
Hydraulics | |
|---|---|
Valves | 0 to 2 |
Pump flow | 12 gpm
45.4 lpm |
Tractor hitch | |
|---|---|
Rear Type | III |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 91 inches
231 cm |
Weight | 10115 lbs
4588 kg |
Front tire | 11.00-16 |
Rear tire | 24.5-32 |
Full dimensions and tires ...  | |
1206 Serial Number Location | |
|---|---|
 | |
On clutch housing, left side |
1206 Serial Numbers | |
|---|---|
1965 | 7501 |
1966 | 7772 |
1967 | 8492 |
FAQ: How to read a serial number table. | |
References | |
|---|---|
 | |
1206 Turbo Tractors published by International Harvester | |
Farm Equipment Reference Catalog published in 1965, by International Harvester |
