international harvester 756
 | 1967 - 1971 | 1967 - 1971 |
|---|---|---|
1967 - 1971 | ||
1967 - 1971 |
|---|
Production | |
|---|---|
Manufacturer | International Harvester |
Factories | Geelong, Australia |
| Rock Island, Illinois, USA |
Original price was $8,300 in 1971 | |
Variants | |
|---|---|
Farmall 756 | row-crop tractor |
International Harvester 756 Engines | |
|---|---|
Interntional Harvester 5.1L 6-cyl diesel | |
International Harvester 4.8L 6-cyl gasoline | |
Fuel tank | 33 gal
124.9 L |
Engine details ...  | |
International Harvester 756 Transmission | |
|---|---|
16-speed two-speed power shift | |
Transmission details ...  |
International Harvester 756 Power | |
|---|---|
Engine | 101 hp
75.3 kW |
Drawbar (claimed) | 69 hp
51.5 kW |
PTO (claimed) | 76 hp
56.7 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Open operator station. Cab optional. |
Photos | |
|---|---|
 | |
International Harvester 756 photos...  |
Hydraulics | |
|---|---|
Type | open center |
Pump flow | 12 gpm
45.4 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@2100 |
| 1000@2100 |
Dimensions & Tires | |
|---|---|
Wheelbase | 101 inches
256 cm |
Weight | 8400 lbs
3810 kg |
Front tire | 7.50-18 |
Rear tire | 18.4-30 |
Full dimensions and tires ...  | |
756 Serial Number Location | |
|---|---|
 | |
Clutch housing, left side. |
756 Serial Numbers | |
|---|---|
1967 (Farmall) | 7501 |
1968 (Farmall) | 9904 |
1969 (Farmall) | 14125 |
1970 (Farmall) | 17832 |
1971 (Farmall) | 18374 |
1967 (IH) | 7501 |
1968 (IH) | 7672 |
1969 (IH) | 8164 |
1970 (IH) | 8284 |
1971 (IH) | 8427 |
FAQ: How to read a serial number table. | |
References | |
|---|---|
 | |
Spring 1968 Buyer's Guide published by International Harvester | |
Summer-Fall 1968 Buyer's Guide published by International Harvester | |
World Wide Farm Equipment Buyer's Guide published in 1968, by International Harvester* | |
Spring 1971 Buyer's Guide published by International Harvester | |
756-856 Tractors published by International Harvester | |
Farm Equipment Reference Catalog published in 1970, by International Harvester | |
*Publication contains known errors. |
