international harvester 986b
 | 1981 - 1982
86B SeriesRow-Crop tractor | 1981 - 1982 | 86B Series | Row-Crop tractor |
|---|---|---|---|---|
1981 - 1982 | ||||
86B Series | ||||
Row-Crop tractor | ||||
1981 - 1982 | |
|---|---|
86B Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | International Harvester |
Row-Crop tractor | |
Built in Geelong, Australia | |
Total built | 328 |
International Harvester 986B Engine | |
|---|---|
International Harvester 5.9L 6-cyl diesel | |
Engine details ...  |
International Harvester 986B Transmission | |
|---|---|
16-speed two-speed power shift | |
Transmission details ...  |
International Harvester 986B Power | |
|---|---|
Engine | 133 hp
99.2 kW |
Drawbar (claimed) | 103 hp
76.8 kW |
PTO (claimed) | 115 hp
85.8 kW |
Mechanical | |
|---|---|
Two-wheel drive | |
Cab standard. |
Photos | |
|---|---|
 | |
International Harvester 986B photos...  |
Capacity | |
|---|---|
Hydraulic system | 22.5 gal
85.2 L |
Hydraulics | |
|---|---|
Capacity | 22.5 gal
85.2 L |
Rear valves | 2 |
Tractor hitch | |
|---|---|
Rear Type | III |
Rear lift (at ends) | 6272 lbs
2844 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Weight | 12434 lbs
5640 kg |
Front tire | 11.00-16 |
Rear tire | 23.1-34 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
International Harvester Australia: Geelong Works by Sarah Tomac* | |
International Harvester Tractors & Equipment in Australia & New Zealand by Graeme Quick | |
Technical Annual published in 1983, by Power Farming | |
*Publication contains known errors. |
