international harvester b 414
 | 1961 - 1966
Utility tractor | 1961 - 1966 | Utility tractor |
|---|---|---|---|
1961 - 1966 | |||
Utility tractor | |||
1961 - 1966 | |
|---|---|
Utility tractor |
Tractor Tests | |
|---|---|
NTTL 817: gasoline 8-speed 2WD | |
NTTL 827: diesel 8-speed 2WD |
Nebraska Tractor Test 817 | ||
|---|---|---|
 | | |
| ||
|
|---|
Nebraska Tractor Test 817 | |
|---|---|
Gasoline 8-speed 2WD
May 3 - 18, 1962
Link: Nebraska Tractor Test 817 file | |
PTO performance | |
Power at rated engine speed | 36.46 hp
27.2 kW |
Fuel use | 3.0 gal/hour
11.4 l/hour |
Drawbar performance | |
Max power | 30.86 hp
23.0 kW |
Fuel use | 3.0 gal/hour
11.4 l/hour |
Gear 4L used for power test. | |
Max pull | 4984 lbs
2260 kg |
Gear 2L used for pull test. | |
Nebraska Tractor Test 827 | ||
|---|---|---|
 | | |
| ||
|
|---|
Nebraska Tractor Test 827 | |
|---|---|
Diesel 8-speed 2WD
September 27 - October 12, 1962
Link: Nebraska Tractor Test 827 file | |
PTO performance | |
Power at rated engine speed | 35.99 hp
26.8 kW |
Fuel use | 2.5 gal/hour
9.5 l/hour |
Drawbar performance | |
Max power | 31.73 hp
23.7 kW |
Fuel use | 2.6 gal/hour
9.8 l/hour |
Gear 4L used for power test. | |
Max pull | 5089 lbs
2308 kg |
Gear 2L used for pull test. | |
