j i case 1070
 | 1970 - 1978
Model year 1970-19731974-1978
70 SeriesRow-Crop tractor | 1970 - 1978 | Model year 1970-19731974-1978 | 70 Series | Row-Crop tractor |
|---|---|---|---|---|---|
1970 - 1978 | |||||
Model year 1970-19731974-1978 | |||||
70 Series | |||||
Row-Crop tractor | |||||
1970 - 1978 | |
|---|---|
Model year 1970-19731974-1978 | |
70 Series | |
Row-Crop tractor |
Tractor Tests | |
|---|---|
NTTL 1035: diesel 8-speed 2WD | |
NTTL 1036: diesel 12-speed 2WD | |
NTTL 1066: diesel (2100 rpm) 12-speed 2WD | |
NTTL 1067: diesel 8-speed 2WD |
Nebraska Tractor Test 1035 | ||
|---|---|---|
 | | |
| ||
|
|---|
Nebraska Tractor Test 1035 | |
|---|---|
Diesel 8-speed 2WD
April 6 - May 2, 1970
Link: Nebraska Tractor Test 1035 file | |
PTO performance | |
Power at rated engine speed | 100.73 hp
75.1 kW |
Fuel use | 6.5 gal/hour
24.6 l/hour |
Power at rated PTO speed | 96.50 hp
72.0 kW |
Fuel use | 6.1 gal/hour
23.1 l/hour |
Drawbar performance | |
Max power | 84.53 hp
63.0 kW |
Fuel use | 6.2 gal/hour
23.5 l/hour |
Gear 4-Low used for power test. | |
Max pull | 11203 lbs
5081 kg |
Gear 2-Low used for pull test. | |
Nebraska Tractor Test 1036 | ||
|---|---|---|
 | | |
| ||
|
|---|
Nebraska Tractor Test 1036 | |
|---|---|
Diesel 12-speed 2WD
April 6 - 20, 1970
Link: Nebraska Tractor Test 1036 file | |
PTO performance | |
Power at rated engine speed | 100.21 hp
74.7 kW |
Fuel use | 6.4 gal/hour
24.2 l/hour |
Power at rated PTO speed | 98.74 hp
73.6 kW |
Fuel use | 6.2 gal/hour
23.5 l/hour |
Drawbar performance | |
Max power | 82.12 hp
61.2 kW |
Fuel use | 6.4 gal/hour
24.2 l/hour |
Gear 2-High used for power test. | |
Max pull | 10912 lbs
4949 kg |
Gear 1-Med used for pull test. | |
Nebraska Tractor Test 1066 | ||
|---|---|---|
 | | |
| ||
|
|---|
Nebraska Tractor Test 1066 | |
|---|---|
Diesel (2100 rpm) 12-speed 2WD
May 7 - 21, 1971
Link: Nebraska Tractor Test 1066 file | |
PTO performance | |
Power at rated engine speed | 108.10 hp
80.6 kW |
Fuel use | 7.2 gal/hour
27.3 l/hour |
Power at rated PTO speed | 99.92 hp
74.5 kW |
Fuel use | 6.5 gal/hour
24.6 l/hour |
Drawbar performance | |
Max power | 90.99 hp
67.9 kW |
Fuel use | 7.2 gal/hour
27.3 l/hour |
Gear 2-Medium used for power test. | |
Max pull | 13780 lbs
6250 kg |
Gear 1-Low used for pull test. | |
Nebraska Tractor Test 1067 | ||
|---|---|---|
 | | |
| ||
|
|---|
Nebraska Tractor Test 1067 | |
|---|---|
Diesel 8-speed 2WD
May 6 - 21, 1971
Link: Nebraska Tractor Test 1067 file | |
PTO performance | |
Power at rated engine speed | 107.36 hp
80.1 kW |
Fuel use | 7.1 gal/hour
26.9 l/hour |
Power at rated PTO speed | 103.91 hp
77.5 kW |
Fuel use | 6.6 gal/hour
25.0 l/hour |
Drawbar performance | |
Max power | 90.77 hp
67.7 kW |
Fuel use | 7.0 gal/hour
26.5 l/hour |
Gear 4-Low used for power test. | |
Max pull | 13116 lbs
5949 kg |
Gear 1-Low used for pull test. | |
