j i case 1194
 | 1983 - 1984
94 SeriesUtility tractor | 1983 - 1984 | 94 Series | Utility tractor |
|---|---|---|---|---|
1983 - 1984 | ||||
94 Series | ||||
Utility tractor | ||||
1983 - 1984 | |
|---|---|
94 Series | |
Utility tractor |
Production | |
|---|---|
Manufacturer | J.I. Case |
Utility tractor | |
Built in Meltham Mills, Huddersfield, England | |
Original price was $17,100 in 1984 | |
J.I. Case 1194 Engine | |
|---|---|
J.I. Case 2.7L 3-cyl diesel | |
Fuel tank | 26.4 gal
99.9 L |
Engine details ...  | |
J.I. Case 1194 Transmission | |
|---|---|
12-speed synchromesh | |
Transmission details ...  |
J.I. Case 1194 Power | |
|---|---|
Engine | 49 hp
36.5 kW |
PTO (claimed) | 43 hp
32.1 kW |
Drawbar (tested) | 34.65 hp
25.8 kW |
PTO (tested) | 43.09 hp
32.1 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two-wheel drive | |
Differential lock | mechanical rear |
Power steering | |
Drum brakes | |
Cab standard. | |
Photos | |
|---|---|
 | |
J.I. Case 1194 photos...  |
Hydraulics | |
|---|---|
Type | open center |
Pressure | 2550 psi
175.8 bar |
Valves | 1 |
Pump flow | 7 gpm
26.5 lpm |
Steering flow | 2 gpm
7.6 lpm |
Tractor hitch | |
|---|---|
Rear Type | II/I |
Rear lift (at 24"/610mm) | 2,180 lbs
988 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 77.5 inches
196 cm |
Weight | 4,650 lbs
2109 kg |
Front tire | 6.00-16 |
Rear tire | 12.4-32 |
Full dimensions and tires ...  | |
J.I. Case 1194 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
1194 Serial Numbers | |
|---|---|
Location: | On frame, right side of engine |
1983 | 11038050 |
1984 | 11038493 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 45 |
Battery CCA | 420 |
| 550 (heavy-duty) |
Battery volts | 12 |
Battery AH | 96 |
| 128 (heavy-duty) |
References | |
|---|---|
 | |
Models 74L & 56L Farm Loaders published in 1983, by J.I. Case | |
1194 - 1294 published in 1983, by J.I. Case | |
94 Series published in 1983, by J.I. Case | |
1194/1294/1394/1494/1594 Tractors published in 1983, by J.I. Case | |
The Tractor Specialist Buyers Guide published in 1984, by J.I. Case | |
Tractor & Loaders Buyers Guide published in 1985, by J.I. Case |
