j i case 1390
 | 1980 - 1983
90 SeriesUtility tractor | 1980 - 1983 | 90 Series | Utility tractor |
|---|---|---|---|---|
1980 - 1983 | ||||
90 Series | ||||
Utility tractor | ||||
1980 - 1983 | |
|---|---|
90 Series | |
Utility tractor |
Production | |
|---|---|
Manufacturer | J.I. Case |
Utility tractor | |
Built in Meltham Mills, Huddersfield, England | |
Original price | $22,100 (1983) |
J.I. Case 1390 Engine | |
|---|---|
J.I. Case 3.6L 4-cyl diesel | |
Engine details ...  |
J.I. Case 1390 Transmission | |
|---|---|
12-speed synchromesh | |
Transmission details ...  |
J.I. Case 1390 Power | |
|---|---|
PTO (claimed) | 60 hp
44.7 kW |
Drawbar (tested) | 50.26 hp
37.5 kW |
PTO (tested) | 60.59 hp
45.2 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Steering | hydrostatic power |
Mechanical drum brakes | |
Two-post ROPS. Cab optional. | |
Capacity | |
|---|---|
Fuel | 19 gal
71.9 L |
Hydraulic system | 7.1 gal
26.9 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 7.1 gal
26.9 L |
Valves | 1 or 2 |
Pump flow | 15.3 gpm
57.9 lpm |
Tractor hitch | |
|---|---|
Rear Type | 2/1 |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 84 inches
213 cm |
Weight | 5,500 lbs
2494 kg |
Front tire | 7.50-16 |
Rear tire | 16.9-30 |
Full dimensions and tires ...  | |
J.I. Case 1390 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
1390 Serial Numbers | |
|---|---|
Location: | Serial number stamped into the top of the tractor's frame on the right side, next to the engine. |
1980 | 11120101 |
1981 | 11122928 |
1982 | 11126132 |
1983 | 11130040 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 26 |
Battery volts | 12 |
References | |
|---|---|
 | |
Model 56L & 66L Farm Loaders published in 1980, by J.I. Case | |
Models 74L & 56L Farm Loaders published in 1983, by J.I. Case | |
1190/1290/1390 General Purpose Tractors published in 1981, by J.I. Case | |
A great new Ninety Series General Purpose line published in 1980, by J.I. Case | |
Power for all-season productivity published in 1982, by J.I. Case | |
The Tractor Specialist Buyers Guide published in 1983, by J.I. Case |
