j i case 211 b
 | 1958 - 1959
200B SeriesRow-Crop tractor | 1958 - 1959 | 200B Series | Row-Crop tractor |
|---|---|---|---|---|
1958 - 1959 | ||||
200B Series | ||||
Row-Crop tractor | ||||
1958 - 1959 | |
|---|---|
200B Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | J.I. Case |
Row-Crop tractor | |
Built in Rock Island, Illinois, USA | |
Total built | 1,641 |
Original price was $2,500 in 1960 | |
Variants | |
|---|---|
210-B | utility |
211-B | row-crop |
J.I. Case 211-B Engine | |
|---|---|
J.I. Case 2.1L 4-cyl gasoline | |
Fuel tank | 13 gal
49.2 L |
Engine details ...  | |
J.I. Case 211-B Transmissions | |
|---|---|
4-speed gear | |
12-speed gear | |
Transmission details ...  |
J.I. Case 211-B Power | |
|---|---|
Drawbar (claimed) | 25 hp
18.6 kW |
PTO (claimed) | 30 hp
22.4 kW |
Plows | 2 |
Drawbar (tested) | 24.84 hp
18.5 kW |
PTO (tested) | 30.84 hp
23.0 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | power assist |
Differential mechanical disc brakes | |
Open operator station. | |
Photos | |
|---|---|
 | |
J.I. Case 211-B photos...  |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540 (1.375) |
Engine RPM | 533@1750 |
Dimensions & Tires | |
|---|---|
Wheelbase | 79.5 inches
201 cm |
Weight | 3655 lbs
1657 kg |
Front tire | 5.00-15 |
Rear tire | 10-28 |
Full dimensions and tires ...  | |
J.I. Case 211-B attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
211-B Serial Number Location | |
|---|---|
 | |
Serial number plate on dashboard. |
Electrical | |
|---|---|
Ground | positive |
Charging system | generator |
Battery volts | 6 |
Battery AH | 100 |
References | |
|---|---|
 | |
Operator's Instruction Manual 200B Series Wheel Tractors (9-462) published in 1958 | |
J.I. Case presents published in 1957 |
