j i case 870

1970 - 1975

70 Series

70 Series

NTTL 1030: diesel 12-speed 2WD

NTTL 1031: diesel 8-speed 2WD

NTTL 1059: gasoline 12-speed 2WD

NTTL 1060: gasoline 8-speed 2WD

NTTL 1076: diesel (2000 rpm) 12-speed 2WD

NTTL 1077: diesel (2000 rpm) 8-speed 2WD

NTTL 1149: diesel (2100 rpm) 8-speed 2WD

NTTL 1150: diesel 12-speed 2WD

Diesel 12-speed 2WD November 10 - 19, 1969 Link: Nebraska Tractor Test 1030 file

PTO performance

Power at rated engine speed

70.53 hp 52.6 kW

Fuel use

4.7 gal/hour 17.8 l/hour

Drawbar performance

Max power

61.38 hp 45.8 kW

Fuel use

4.7 gal/hour 17.8 l/hour

Gear 2-High used for power test.

Max pull

8876 lbs 4026 kg

Gear 1-High used for pull test.

Diesel 8-speed 2WD November 10 - 20, 1969 Link: Nebraska Tractor Test 1031 file

PTO performance

Power at rated engine speed

70.67 hp 52.7 kW

Fuel use

4.5 gal/hour 17.0 l/hour

Drawbar performance

Max power

61.77 hp 46.1 kW

Fuel use

4.3 gal/hour 16.3 l/hour

Gear 4-Low used for power test.

Max pull

8934 lbs 4052 kg

Gear 2-Low used for pull test.

Gasoline 12-speed 2WD October 28 - November 17, 1970 Link: Nebraska Tractor Test 1059 file

PTO performance

Power at rated engine speed

70.67 hp 52.7 kW

Fuel use

6.3 gal/hour 23.8 l/hour

Drawbar performance

Max power

58.03 hp 43.3 kW

Fuel use

6.1 gal/hour 23.1 l/hour

Gear 2-High used for power test.

Max pull

8793 lbs 3988 kg

Gear 1-Med used for pull test.

Gasoline 8-speed 2WD October 28 - November 7, 1970 Link: Nebraska Tractor Test 1060 file

PTO performance

Power at rated engine speed

71.06 hp 53.0 kW

Fuel use

6.0 gal/hour 22.7 l/hour

Drawbar performance

Max power

62.52 hp 46.6 kW

Fuel use

6.2 gal/hour 23.5 l/hour

Gear 4-Low used for power test.

Max pull

9105 lbs 4130 kg

Gear 2-Low used for pull test.

Diesel (2000 rpm) 12-speed 2WD Link: Nebraska Tractor Test 1076 file

PTO performance

Power at rated engine speed

77.92 hp 58.1 kW

Fuel use

5.5 gal/hour 20.8 l/hour

Power at rated PTO speed

77.11 hp 57.5 kW

Fuel use

5.5 gal/hour 20.8 l/hour

Drawbar performance

Max power

66.89 hp 49.9 kW

Fuel use

5.5 gal/hour 20.8 l/hour

Gear 3-Low used for power test.

Max pull

10075 lbs 4570 kg

Gear 1-Med used for pull test.

Diesel (2000 rpm) 8-speed 2WD September 12 - 24, 1971 Link: Nebraska Tractor Test 1077 file

PTO performance

Power at rated engine speed

77.45 hp 57.8 kW

Fuel use

5.0 gal/hour 18.9 l/hour

Power at rated PTO speed

76.63 hp 57.1 kW

Fuel use

5.0 gal/hour 18.9 l/hour

Drawbar performance

Max power

69.04 hp 51.5 kW

Fuel use

5.2 gal/hour 19.7 l/hour

Gear 4-Low used for power test.

Max pull

9733 lbs 4414 kg

Gear 1-Low used for pull test.

Diesel (2100 rpm) 8-speed 2WD October 22 - 31, 1973 Link: Nebraska Tractor Test 1149 file

PTO performance

Power at rated engine speed

80.20 hp 59.8 kW

Fuel use

5.7 gal/hour 21.6 l/hour

Power at rated PTO speed

77.93 hp 58.1 kW

Fuel use

5.4 gal/hour 20.4 l/hour

Drawbar performance

Max power

69.53 hp 51.8 kW

Fuel use

5.6 gal/hour 21.2 l/hour

Gear 4-Low used for power test.

Max pull

10047 lbs 4557 kg

Gear 1-Low used for pull test.

Diesel 12-speed 2WD October 26 - November 6, 1973 Link: Nebraska Tractor Test 1150 file

PTO performance

Power at rated engine speed

80.49 hp 60.0 kW

Fuel use

6.0 gal/hour 22.7 l/hour

Power at rated PTO speed

76.52 hp 57.1 kW

Fuel use

5.6 gal/hour 21.2 l/hour

Drawbar performance

Max power

68.90 hp 51.4 kW

Fuel use

6.0 gal/hour 22.7 l/hour

Gear 3-Low used for power test.

Max pull

10030 lbs 4549 kg

Gear 1-Med used for pull test.
