john deere 1745f
 | 1987 - 1990
45F SeriesOrchard/Vineyard tractorGoldoni built | 1987 - 1990 | 45F Series | Orchard/Vineyard tractor | Goldoni built |
|---|---|---|---|---|---|
1987 - 1990 | |||||
45F Series | |||||
Orchard/Vineyard tractor | |||||
Goldoni built | |||||
1987 - 1990 | |
|---|---|
45F Series | |
Orchard/Vineyard tractor | |
Goldoni built |
Production | |
|---|---|
Distributor | John Deere |
Manufacturer | Goldoni |
Orchard/Vineyard tractor | |
Built in Italy | |
John Deere 1745F Engine | |
|---|---|
John Deere 2.9L 3-cyl diesel | |
Fuel tank | 10.6 gal
40.1 L |
Engine details ...  | |
John Deere 1745F Transmissions | |
|---|---|
8-speed synchronized | |
16-speed creeper | |
Transmission details ...  |
John Deere 1745F Power | |
|---|---|
Engine | 47.3 hp
35.3 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Differential lock | mechanical rear |
Power steering | |
Mechanical wet disc brakes | |
Two-post mid-mount folding ROPS. Quick-mount cab available. | |
Hydraulics | |
|---|---|
Type | open center |
Pressure | 2611 psi
180.0 bar |
Rear valves | 3 |
Mid valves | 3 |
Pump flow | 8.7 gpm
32.9 lpm |
| 17.4 gpmOptOptional
65.9 lpm |
Tractor hitch | |
|---|---|
Rear Type | IIN/I |
Control | top-link draft sensing |
Rear lift (at 24"/610mm) | 3197 lbs
1450 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@2165 |
| 540E@1624 |
Dimensions & Tires | |
|---|---|
Wheelbase | 72.2 inches
183 cm |
Weight | 4057 to 4641 pounds |
Front tire | 7.00-12 |
2WD Low-Profile Rear tire | 12.4-24 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 35 |
Battery volts | 12 |
Battery AH | 100 |
References | |
|---|---|
 | |
Orchard Tractors published in 1989, by John Deere |
