john deere 3010

1961 - 1963

New Generation Series

Row-Crop tractor

New Generation Series

Row-Crop tractor

NTTL 762: diesel 8-speed 2WD

NTTL 763: gasoline 8-speed 2WD

NTTL 764: LP gas 8-speed 2WD

Diesel 8-speed 2WD September 19 - 24, 1960 Link: Nebraska Tractor Test 762 file

PTO performance

Power at rated engine speed

59.44 hp 44.3 kW

Fuel use

4.1 gal/hour 15.5 l/hour

Power at rated PTO speed

55.29 hp 41.2 kW

Fuel use

3.6 gal/hour 13.6 l/hour

Drawbar performance

Max power

52.77 hp 39.4 kW

Fuel use

4.1 gal/hour 15.5 l/hour

Gear 4 used for power test.

Max pull

6,323 lbs 2868 kg

Gear 6,323 used for pull test.

Gasoline 8-speed 2WD September 24 - 28, 1960 Link: Nebraska Tractor Test 763 file

PTO performance

Power at rated engine speed

55.09 hp 41.1 kW

Fuel use

5.1 gal/hour 19.3 l/hour

Power at rated PTO speed

50.54 hp 37.7 kW

Fuel use

4.8 gal/hour 18.2 l/hour

Drawbar performance

Max power

50.98 hp 38.0 kW

Fuel use

5.2 gal/hour 19.7 l/hour

Gear 4 used for power test.

Max pull

6,660 lbs 3020 kg

Gear 2 used for pull test.

LP gas 8-speed 2WD September 24 - 29, 1960 Link: Nebraska Tractor Test 764 file

PTO performance

Power at rated engine speed

55.39 hp 41.3 kW

Fuel use

6.5 gal/hour 24.6 l/hour

Power at rated PTO speed

50.80 hp 37.9 kW

Fuel use

5.9 gal/hour 22.3 l/hour

Drawbar performance

Max power

49.22 hp 36.7 kW

Fuel use

6.5 gal/hour 24.6 l/hour

Gear 4 used for power test.

Max pull

6,598 lbs 2992 kg

Gear 2 used for pull test.
