john deere 3020

overview engine transmission dimensions tests attachments

	1964 - 1972 Model year 1964-19681969-1972 New Generation SeriesRow-Crop tractor	1964 - 1972	Model year 1964-19681969-1972	New Generation Series	Row-Crop tractor
1964 - 1972
Model year 1964-19681969-1972
New Generation Series
Row-Crop tractor

1964 - 1972
Model year 1964-19681969-1972
New Generation Series
Row-Crop tractor

Tractor Tests
NTTL 848: diesel Powershift 2WD
NTTL 851: gasoline Powershift 2WD
NTTL 852: LP gas Powershift 2WD
NTTL 940: diesel Syncro-Range 2WD
NTTL 941: gasoline Syncro-Range 2WD
NTTL 942: LP gas Syncro-Range 2WD

Nebraska Tractor Test 848

Nebraska Tractor Test 848
Diesel Powershift 2WD September 23 - October 2, 1963 Link: Nebraska Tractor Test 848 file
PTO performance
Power at rated engine speed	65.28 hp 48.7 kW
Fuel use	5.1 gal/hour 19.3 l/hour
Power at rated PTO speed	59.25 hp 44.2 kW
Fuel use	4.3 gal/hour 16.3 l/hour
Drawbar performance
Max power	54.77 hp 40.8 kW
Fuel use	5.0 gal/hour 18.9 l/hour
Gear 4 used for power test.
Max pull	7536 lbs 3418 kg
Gear 2 used for pull test.

Nebraska Tractor Test 851

Nebraska Tractor Test 851
Gasoline Powershift 2WD September 30 - October 7, 1963 Link: Nebraska Tractor Test 851 file
PTO performance
Power at rated engine speed	64.14 hp 47.8 kW
Fuel use	6.2 gal/hour 23.5 l/hour
Power at rated PTO speed	59.33 hp 44.2 kW
Fuel use	5.6 gal/hour 21.2 l/hour
Drawbar performance
Max power	54.60 hp 40.7 kW
Fuel use	6.2 gal/hour 23.5 l/hour
Gear 4 used for power test.
Max pull	7,621 lbs 3456 kg
Gear 2 used for pull test.

Nebraska Tractor Test 852

Nebraska Tractor Test 852
LP gas Powershift 2WD October 2 - 11, 1963 Link: Nebraska Tractor Test 852 file
PTO performance
Power at rated engine speed	64.70 hp 48.2 kW
Fuel use	8.0 gal/hour 30.3 l/hour
Power at rated PTO speed	56.34 hp 42.0 kW
Fuel use	6.4 gal/hour 24.2 l/hour
Drawbar performance
Max power	54.50 hp 40.6 kW
Fuel use	7.7 gal/hour 29.1 l/hour
Gear 4 used for power test.
Max pull	7,725 lbs 3504 kg
Gear 2 used for pull test.

Nebraska Tractor Test 940

Nebraska Tractor Test 940
Diesel Syncro-Range 2WD May 17 - 25, 1966 Link: Nebraska Tractor Test 940 file
PTO performance
Power at rated engine speed	71.26 hp 53.1 kW
Fuel use	5.1 gal/hour 19.3 l/hour
Power at rated PTO speed	64.32 hp 48.0 kW
Fuel use	4.4 gal/hour 16.7 l/hour
Drawbar performance
Max power	61.47 hp 45.8 kW
Fuel use	4.9 gal/hour 18.5 l/hour
Gear 4 used for power test.
Max pull	7596 lbs 3445 kg
Gear 2 used for pull test.

Nebraska Tractor Test 941

Nebraska Tractor Test 941
Gasoline Syncro-Range 2WD May 31 - June 7, 1966 Link: Nebraska Tractor Test 941 file
PTO performance
Power at rated engine speed	70.59 hp 52.6 kW
Fuel use	6.6 gal/hour 25.0 l/hour
Power at rated PTO speed	64.74 hp 48.3 kW
Fuel use	6.1 gal/hour 23.1 l/hour
Drawbar performance
Max power	61.38 hp 45.8 kW
Fuel use	6.2 gal/hour 23.5 l/hour
Gear 4 used for power test.
Max pull	7558 lbs 3428 kg
Gear 2 used for pull test.

Nebraska Tractor Test 942

Nebraska Tractor Test 942
LP gas Syncro-Range 2WD May 31 - June 8, 1966 Link: Nebraska Tractor Test 942 file
PTO performance
Power at rated engine speed	70.66 hp 52.7 kW
Fuel use	8.2 gal/hour 31.0 l/hour
Power at rated PTO speed	62.88 hp 46.9 kW
Fuel use	6.7 gal/hour 25.4 l/hour
Drawbar performance
Max power	63.13 hp 47.1 kW
Fuel use	8.1 gal/hour 30.7 l/hour
Gear 4 used for power test.
Max pull	7680 lbs 3483 kg
Gear 2 used for pull test.
