john deere 3033r

2014 -

3R Series

Compact Utility tractor

3R Series

Compact Utility tractor

Manufacturer

John Deere

Compact Utility tractor

Yanmar 1.6L 3-cyl diesel

hydrostatic

Engine (gross)

32.8 hp 24.5 kW

Engine (net)

31.4 hp 23.4 kW

PTO (claimed)

25 hp 18.6 kW

Four-wheel drive

Final drives

spur gear

Differential lock

mechanical rear

Power steering

Wet disc brakes

Two-post folding ROPS. Cab optional.

ROPS Fuel

13.5 gal 51.1 L

Cab Fuel

11.9 gal 45.0 L

Hydraulic system

6.8 gal 25.7 L

Type

open center

Capacity

6.8 gal 25.7 L

Pump flow

8.6 gpm 32.6 lpm

Total flow

13.9 gpm 52.6 lpm

Steering flow

5.3 gpm 20.1 lpm

Rear Type

I

Rear lift (at ends)

2531 lbs 1148 kg

Rear lift (at 24"/610mm)

2202 lbs 998 kg

Front Hitch

0/I OptOptional

Front lift (at ends)

2430 lbs 1102 kg

Rear PTO

independent

Clutch

wet disc

Rear PTO Type

540 (1.375)

Mid PTO

independent *Standard with hydrostatic, optional with PowrReverser.

Mid PTO Type

2100

Front PTO

independent OptOptional

Front PTO Type

2100

Wheelbase

68 inches 172 cm

Weight

3086 to 3748 pounds

Front tire

7.00-14

Rear tire

11.2-24

backhoe

Ground

negative

Charging system

alternator

Battery volts

12
