john deere 5085m
 | 2008 - 2018
Model year 2008-20112012-20142015-2018
5M SeriesUtility tractor | 2008 - 2018 | Model year 2008-20112012-20142015-2018 | 5M Series | Utility tractor |
|---|---|---|---|---|---|
2008 - 2018 | |||||
Model year 2008-20112012-20142015-2018 | |||||
5M Series | |||||
Utility tractor | |||||
2008 - 2018 | |
|---|---|
Model year 2008-20112012-20142015-2018 | |
5M Series | |
Utility tractor |
Production | |
|---|---|
Manufacturer | John Deere |
Utility tractor | |
Built in Augusta, Georgia, USA | |
Original price | $41,671 (2WD ROPS) |
| $52,340 (4WD cab) |
John Deere 5085M Engine | |
|---|---|
John Deere 4.5L 4-cyl diesel | |
Engine details ...  |
John Deere 5085M Transmissions | |
|---|---|
16-speed partially synchronized | |
12-speed partially synchronized | |
16-speed partially synchronized with power shuttle | |
32-speed | |
Transmission details ...  |
John Deere 5085M Power | |
|---|---|
Engine | 85 hp
63.4 kW |
PTO (claimed) | 70 hp
52.2 kW |
PTO (tested) | 74.07 hp
55.2 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Drive | 4x2 2WD |
| 4x4 MFWD 4WD (optional) |
Final drives | inboard planetary |
Differential lock | shift-on-the-move electro-hydraulic rear differential lock |
Steering | hydrostatic power |
Hydraulic wet disc brakes | |
Foldable ROPS. Optional deluxe ROPS with upgraded seat. Optional cab with heat and air conditioning. | |
Photos | |
|---|---|
 | |
John Deere 5085M photos...  |
Capacity | |
|---|---|
Fuel | 30.3 gal (ROPS)
114.7 L |
| 40.7 gal (cab)
154.0 L |
Hydraulic system | 11.9 gal
45.0 L |
Front hubs | 0.84 qts (each)
0.8 L |
Front diff. | 5.3 qts
5.0 L |
Hydraulics | |||||||
|---|---|---|---|---|---|---|---|
Type | open center | ||||||
Capacity | 11.9 gal
45.0 L | ||||||
Pressure | 2828 psi
195.0 bar | ||||||
Valves | 0, 2 or 3 (rear) | ||||||
| 0, 2 or 3 (mid) | ||||||
Pump flow | 18.4 gpm
69.6 lpm | ||||||
Total flow | 24.7 gpm
93.5 lpm | ||||||
Oil type | -10oF [-23oC]↑ : HY-GARD -10oF [-23oC]↑ : JDM J20C 10o↔104oF [-12o↔40oC] : BIO HY-GARD JDM 20D | -10oF [-23oC]↑ | : HY-GARD | -10oF [-23oC]↑ | : JDM J20C | 10o↔104oF [-12o↔40oC] | : BIO HY-GARD JDM 20D |
-10oF [-23oC]↑ | : HY-GARD | ||||||
-10oF [-23oC]↑ | : JDM J20C | ||||||
10o↔104oF [-12o↔40oC] | : BIO HY-GARD JDM 20D | ||||||
Steering flow | 6.3 gpm
23.8 lpm | ||||||
Steering press. | 1922 psi
132.5 bar | ||||||
-10oF [-23oC]↑ | : HY-GARD |
|---|---|
-10oF [-23oC]↑ | : JDM J20C |
10o↔104oF [-12o↔40oC] | : BIO HY-GARD JDM 20D |
Tractor hitch | |
|---|---|
Rear Type | II/I |
Rear lift (at 24"/610mm) | 3,595 lbs
1630 kg |
| 4,498 lbs (optional)
2040 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent electrohydraulic |
Rear PTO Type | 540/540E |
| 540/540E/1000 (optional) |
Dimensions & Tires | |
|---|---|
Weight | 6393 to 8000 pounds |
Front tire | 7.5-16 |
Rear tire | 16.9-30 |
Full dimensions and tires ...  | |
John Deere 5085M attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
5085M Serial Number Location | |
|---|---|
 | |
Tractor frame on front left side. |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 70 (ROPS) |
| 90 (cab) |
| 120 (optional) |
Battery CCA | 925 |
Battery volts | 12 |
Battery Group | 31 |
References | |
|---|---|
 | |
New 5M Series published in 2009, by John Deere | |
5M Series published in 2011, by John Deere |
