john deere 5100gf
 | 2009 - 2013
5G SeriesOrchard/Vineyard tractorAgritalia built | 2009 - 2013 | 5G Series | Orchard/Vineyard tractor | Agritalia built |
|---|---|---|---|---|---|
2009 - 2013 | |||||
5G Series | |||||
Orchard/Vineyard tractor | |||||
Agritalia built | |||||
2009 - 2013 | |
|---|---|
5G Series | |
Orchard/Vineyard tractor | |
Agritalia built |
Production | |
|---|---|
Distributor | John Deere |
Manufacturer | Agritalia |
Orchard/Vineyard tractor | |
Built in Rovigo, Italy | |
Variants | |
|---|---|
5100GF | orchard |
5100GV | vineyard |
John Deere 5100GF Engine | |
|---|---|
John Deere 4.5L 4-cyl diesel | |
Fuel tank | 40.2 gal
152.2 L |
Engine details ...  | |
John Deere 5100GF Transmissions | |
|---|---|
12-speed | |
24-speed | |
Transmission details ...  |
John Deere 5100GF Power | |
|---|---|
Engine | 100 hp
74.6 kW |
Mechanical | |
|---|---|
Drive | 4x2 2WD |
| 4x4 MFWD 4WD (optional) |
Steering | hydrostatic power |
Wet disc brakes | |
ROPS (2-post); Cab optional. | |
Hydraulics | |
|---|---|
Pressure | 2700 psi
186.2 bar |
Pump flow | 11.9 gpm
45.0 lpm |
| 15.6 gpm (optional)
59.0 lpm |
Total flow | 18.9 gpm
71.5 lpm |
| 22.3 gpm (optional)
84.4 lpm |
| 27.6 gpm (optional)
104.5 lpm |
Steering flow | 6.5 gpm
24.6 lpm |
Steering press. | 1900 psi
131.0 bar |
Tractor hitch | |
|---|---|
Rear Type | II/I |
Rear lift | 5,845 lbs
2651 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540/540E/ground |
| 540/1000/ground |
Dimensions & Tires | |
|---|---|
Wheelbase | 85 inches
215 cm |
Weight | 5776 to 6460 pounds |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 45 |
| 95 (cab) |
Battery volts | 12 |
Battery AH | 100 |
References | |
|---|---|
 | |
5 Series Speciality tractors published in 2009, by John Deere |
