john deere 5125r
 | 2017 -
5R SeriesUtility tractor | 2017 - | 5R Series | Utility tractor |
|---|---|---|---|---|
2017 - | ||||
5R Series | ||||
Utility tractor | ||||
2017 - | |
|---|---|
5R Series | |
Utility tractor |
Production | |
|---|---|
Manufacturer | John Deere |
Utility tractor | |
Built in Augusta, Georgia, USA | |
Original price was $99,029 in 2019 | |
John Deere 5125R Engine | |
|---|---|
John Deere 4.5L 4-cyl diesel | |
Engine details ...  |
John Deere 5125R Transmissions | |
|---|---|
16-speed | |
24-speed | |
32-speed | |
Transmission details ...  |
John Deere 5125R Power | |
|---|---|
Engine | 125 hp
93.2 kW |
Open center PTO (claimed) | 110 hp
82.0 kW |
PFC PTO (claimed) | 115 hp
85.8 kW |
PTO (tested) | 124.57 hp
92.9 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Four-wheel drive | |
Final drives | inboard planetary |
Differential lock | electro-hydraulic |
Power steering | |
Cab standard with air-conditioning. | |
Capacity | |
|---|---|
Fuel | 38 gal
143.8 L |
Exhaust fluid (DEF) | 2.9 gal
11.0 L |
Open center Hydraulic system | 11.75 gal
44.5 L |
PFC Hydraulic system | 12.5 gal
47.3 L |
Hydraulics | |
|---|---|
Open center Type | open center |
PFC Type | pressure-flow compensated |
Open center Capacity | 11.75 gal
44.5 L |
PFC Capacity | 12.5 gal
47.3 L |
Pressure | 2900 psi
200.0 bar |
Open center SCV flow | 19.3 gpm
73.1 lpm |
PFC SCV flow | 26.4 gpm
99.9 lpm |
Open center Total flow | 25.5 gpm
96.5 lpm |
PFC Total flow | 39 gpm
147.6 lpm |
Open center Steering flow | 6.2 gpm
23.5 lpm |
PFC Steering flow | 8.1 gpm
30.7 lpm |
Tractor hitch | |
|---|---|
Rear Type | II/I |
Control | electro-hydraulic draft sensing |
Rear lift (at ends) | 7158 lbs
3246 kg |
| 8157 lbsOptOptional
3700 kg |
Rear lift (at 24"/610mm) | 6979 lbs
3165 kg |
| 7868 lbsOptOptional
3568 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic |
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@2100 |
| 540E@1645 |
| 1000@2103 |
Dimensions & Tires | |
|---|---|
Wheelbase | 88.6 inches
225 cm |
Weight | 9811 lbs
4450 kg |
Front tire | 12.4R24 |
Rear tire | 18.4R30 |
Full dimensions and tires ...  | |
John Deere 5125R attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
5125R Serial Numbers | |
|---|---|
Location: | Serial number plate on the right side of the 5125R frame, above the front axle. |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 200 |
Battery CCA | 950 |
Battery volts | 12 |
References | |
|---|---|
 | |
5R Series Tractors published in 2018, by John Deere | |
Get a load of Our new 5R options published in 2018, by John Deere |
