john deere 5725
 | 2006 - 2012
5025 SeriesUtility tractor | 2006 - 2012 | 5025 Series | Utility tractor |
|---|---|---|---|---|
2006 - 2012 | ||||
5025 Series | ||||
Utility tractor | ||||
2006 - 2012 | |
|---|---|
5025 Series | |
Utility tractor |
Production | |
|---|---|
Manufacturer | John Deere |
Utility tractor | |
Built in Saltillo, Mexico | |
Variants | |
|---|---|
5725O | orchard |
5725HC | high-crop |
John Deere 5725 Engine | |
|---|---|
John Deere 4.6L 4-cyl diesel | |
OOS Fuel tank | 25 gal
94.6 L |
IOOS Fuel tank | 37 gal
140.0 L |
Cab Fuel tank | 37 gal
140.0 L |
PowrReverser Cab Fuel tank | 33 gal
124.9 L |
Engine details ...  | |
John Deere 5725 Transmissions | |
|---|---|
9-speed gear | |
9-speed partially synchronized | |
12-speed power shuttle | |
Transmission details ...  |
John Deere 5725 Power | |
|---|---|
Engine | 89 hp
66.4 kW |
PTO (claimed) | 77 hp
57.4 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Hydraulic wet disc brakes | |
Two-post fixed ROPS. Foldable ROPS optional. Optional isolate platform (IOOS). Cab optional with air-conditioning. |
Hydraulics | |
|---|---|
Type | open center |
Pressure | 2800 psi
193.1 bar |
Pump flow | 15.9 gpm
60.2 lpm |
Steering flow | 6.6 gpm
25.0 lpm |
Steering press. | 1900 psi
131.0 bar |
Tractor hitch | |
|---|---|
Rear Type | II/I |
Control | top-link draft sensing |
Rear lift (at 24"/610mm) | 3374 lbs
1530 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 (1.375) |
Engine RPM | 540@2400 |
| 540E@1700 |
Dimensions & Tires | |
|---|---|
Wheelbase | 85.8 inches
217 cm |
Weight | 5512 to 7130 pounds |
Front tire | 12.4x24 |
Rear tire | 18.4x30 |
Full dimensions and tires ...  | |
5725 Serial Numbers | |
|---|---|
Location: | Serial number plate on the left side of the tractor frame, above the front axle. |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
ROPS Charging amps | 70 |
Cab Charging amps | 90 |
Battery CCA | 550 |
Battery volts | 12 |
Battery Group | 27F |
References | |
|---|---|
 | |
Tractores Serie 5025 published in 2007, by John Deere |
