john deere 7200
 | 1993 - 1996
7000 SeriesRow-Crop tractor | 1993 - 1996 | 7000 Series | Row-Crop tractor |
|---|---|---|---|---|
1993 - 1996 | ||||
7000 Series | ||||
Row-Crop tractor | ||||
1993 - 1996 | |
|---|---|
7000 Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | John Deere |
Row-Crop tractor | |
Built in Waterloo, Iowa, USA | |
Original price was $50,000 in 1996 | |
John Deere 7200 Engine | |
|---|---|
John Deere 5.9L 6-cyl diesel | |
Fuel tank | 54 gal
204.4 L |
Engine details ...  | |
John Deere 7200 Transmissions | |
|---|---|
12-speed fully synchronized | |
16-speed four-speed power shift | |
Transmission details ...  |
John Deere 7200 Power | |
|---|---|
PTO (claimed) | 92 hp
68.6 kW |
Drawbar (tested) | 85.86 hp
64.0 kW |
PTO (tested) | 97.88 hp
73.0 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Independent hydraulic wet disc brakes | |
Cab standard with air-conditioning. |
Photos | |
|---|---|
 | |
John Deere 7200 photos...  |
Hydraulics | |
|---|---|
Type | closed center |
Valves | 2 or 3 |
Tractor hitch | |
|---|---|
Rear Type | 2/3N |
Rear lift (at 24"/610mm) | 6,858 lbs
3110 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 112.1 inches
284 cm |
Weight | 12678 lbs
5750 kg |
Front tire | 10.00x16 |
Rear tire | 18.4x38 |
Full dimensions and tires ...  | |
7200 Serial Numbers | |
|---|---|
1994 | 1001 |
1995 | 2595 |
1996 | 4001 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
