john deere 830
 | 1974 - 1979
Utility tractor | 1974 - 1979 | Utility tractor |
|---|---|---|---|
1974 - 1979 | |||
Utility tractor | |||
1974 - 1979 | |
|---|---|
Utility tractor |
Production | |
|---|---|
Manufacturer | John Deere |
Utility tractor | |
Built in Mannheim, Baden-Württemberg, Germany | |
John Deere 830 Engine | |
|---|---|
John Deere 2.7L 3-cyl diesel | |
Engine details ...  |
John Deere 830 Transmission | |
|---|---|
8-speed gear | |
Transmission details ...  |
John Deere 830 Power | |
|---|---|
Engine (net) | 35 hp
26.1 kW |
PTO (claimed) | 29.5 hp
22.0 kW |
Mechanical | |
|---|---|
Two-wheel drive | |
Final drives | planetary |
Differential lock | mechanical rear |
Manual steering | |
Wet disc brakes | |
Capacity | |
|---|---|
Fuel | 16.4 gal
62.1 L |
Hydraulic system | 7.9 gal
29.9 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 7.9 gal
29.9 L |
Pressure | 2104 psi
145.1 bar |
Pump flow | 6.3 gpm
23.8 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Control | position and draft control |
Rear lift | 3417 lbs
1549 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | dry disc |
Rear PTO Type | 540 (1.375) |
Engine RPM | 540@2100 |
Dimensions & Tires | |
|---|---|
Wheelbase | 74.4 inches
188 cm |
Weight | 4740 lbs
2150 kg |
Front tire | 6.00-16 |
Rear tire | 13.6/12-28 |
Full dimensions and tires ...  | |
830 Serial Numbers | |
|---|---|
Location: | Serial number plate on the right side of the Deere 830 tractor frame, above the front axle. |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 28 |
Battery volts | 12 |
Battery AH | 55 |
References | |
|---|---|
 | |
Operator's Manual Tractors 830 and 930 (OML31437) | |
Operator's Manual Tractors 830 and 930 (OML33962) | |
Product Information Manual published in 1975, by John Deere | |
Product Information Manual published in 1977, by John Deere |
