john deere 8530
 | 2006 - 2009
8030 SeriesRow-Crop tractor | 2006 - 2009 | 8030 Series | Row-Crop tractor |
|---|---|---|---|---|
2006 - 2009 | ||||
8030 Series | ||||
Row-Crop tractor | ||||
2006 - 2009 | |
|---|---|
8030 Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | John Deere |
Row-Crop tractor | |
Built in Waterloo, Iowa, USA | |
John Deere 8530 Engine | |
|---|---|
John Deere 9.0L 6-cyl diesel | |
Engine details ...  |
John Deere 8530 Power | |
|---|---|
Engine (gross) | 330 hp
246.1 kW |
Engine (max) | 360 hp
268.5 kW |
PTO (claimed) | 275 hp
205.1 kW |
Drawbar (tested) | 240.35 hp
179.2 kW |
PTO (tested) | 312.73 hp
233.2 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Drive | 4x4 Independent Link Suspension MFWD 4WD (ILS) |
Power steering | |
Hydraulic wet disc brakes | |
CommandView cab standard. | |
Photos | |
|---|---|
 | |
John Deere 8530 photos...  |
Capacity | |
|---|---|
Fuel | 180 gal
681.3 L |
Hydraulic system | 9.5 gal
36.0 L |
| 14.5 gal (with aux reservoir)
54.9 L |
Hydraulics | |
|---|---|
Type | closed center pressure-flow compensating PFC |
Capacity | 9.5 gal
36.0 L |
| 14.5 gal (with aux reservoir)
54.9 L |
Pressure | 2990 psi
206.2 bar |
Valves | 3 to 5 |
Pump flow | 31.7 gpm
120.0 lpm |
Total flow | 60 gpm
227.1 lpm |
Tractor hitch | |
|---|---|
Rear Type | IVN/III |
Rear lift (at 24"/610mm) | 18,326 lbs
8312 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 1000 |
| 540/1000 (optional) |
Engine RPM | 540@1817 |
| 1000@2000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 118.9 inches
302 cm |
Weight | 26,800 lbs
12156 kg |
Full dimensions and tires ...  | |
8530 Serial Number Location | |
|---|---|
 | |
Rear of tractor |
8530 Serial Numbers | |
|---|---|
2006 | 1001 |
2007 | 10005 |
2008 | 20007 |
2009 | 40000 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 200 |
Batteries | 2 |
Battery CCA | 925 |
Battery volts | 12 |
References | |
|---|---|
 | |
8030 Series 2007 Updates published by John Deere |
