john deere lawn tractors 300
 | 1975 - 1977
300 SeriesGarden tractor | 1975 - 1977 | 300 Series | Garden tractor |
|---|---|---|---|---|
1975 - 1977 | ||||
300 Series | ||||
Garden tractor | ||||
1975 - 1977 | |
|---|---|
300 Series | |
Garden tractor |
Production | |
|---|---|
Manufacturer | John Deere |
Garden tractor | |
Built in Horicon, Wisconsin, USA | |
Original price was $2,695 in 1977 | |
John Deere 300 Engine | |
|---|---|
16HP Kohler 588cc 1-cyl gasoline | |
Fuel tank | 4.5 gal
17.0 L |
Engine details ...  | |
John Deere 300 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Photos | |
|---|---|
 | |
John Deere 300 photos...  |
Hydraulics | |
|---|---|
Type | open center |
Front valves | 1 |
| 2 OptOptional |
Tractor hitch | |
|---|---|
Rear Type | 0 OptOptional |
Type | sleeve hitch OptOptional |
Power Take-off (PTO) | |
|---|---|
Front PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 46 inches
116 cm |
Weight | 700 lbs
317 kg |
Front tire | 16x6.50-8 |
Rear tire | 23x8.50-12 |
Full dimensions and tires ...  | |
John Deere 300 attachments | |
|---|---|
38" mid-mount mower deck | |
46" mid-mount mower deck | |
snowblower | |
blade | |
front-end loader | |
backhoe | |
Attachment details ...  |
300 Serial Number Location | |
|---|---|
 | |
Serial number plate below the steering column of the John Deere 300. |
300 Serial Numbers | |
|---|---|
1975 | C300D30001 |
1976 | C300E55001 |
1977 | C300F70001 |
Final | C300F80000 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Lawn and Garden Tractors published in 1975, by John Deere | |
Lawn and Garden Tractors published in 1976, by John Deere | |
Matched Working Equipment for John Deere Lawn and Garden Tractors published in 1975 | |
 | |
Operator's Manual 300 Hydrostatic Tractor (OMM49673) published in 1975 | |
Operator's Manual 300 Hydrostatic Tractor (OMM80641) published in 1976 | |
Operator's Manual 41 and 48 Rotary Mowers (OMM49677) | |
Operator's Manual 49 Snowthrower (OMM89078) published in 1986 |
 | |
|---|---|
