john deere lawn tractors x724
 | 2006 - 2012
Select X700 SeriesGarden tractor | 2006 - 2012 | Select X700 Series | Garden tractor |
|---|---|---|---|---|
2006 - 2012 | ||||
Select X700 Series | ||||
Garden tractor | ||||
2006 - 2012 | |
|---|---|
Select X700 Series | |
Garden tractor |
Production | |
|---|---|
Manufacturer | John Deere |
Garden tractor | |
Built in Horicon, Wisconsin, USA | |
Original price was $9,729 in 2011 | |
Variants | |
|---|---|
X720 | two-wheel drive |
X724 | 2WD, all-wheel steer |
X728 | four-wheel drive |
X729 | 4WD, all-wheel steer |
John Deere X724 Engine | |
|---|---|
27HP Kawasaki 745cc 2-cyl gasoline | |
Fuel tank | 6.5 gal (2006-2010)
24.6 L |
| 5.2 gal (2011-)
19.7 L |
Engine details ...  | |
John Deere X724 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | four-wheel hydrostatic power |
Wet disc brakes | |
Open operator station featuring 18-inch seat with 7-inches of adjustment. Cupholder, toolbox, tilt steering, and 12-volt outlet standard. Optional soft-side or hard cab. | |
Photos | |
|---|---|
 | |
John Deere X724 photos...  |
Hydraulics | |
|---|---|
Pressure | 924 psi
63.7 bar |
Valves | 2 |
Total flow | 4.5 gpm
17.0 lpm |
Tractor hitch | |
|---|---|
Rear Type | 0 (optional) |
| 1-Limited (optional) |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent (optional) |
Rear PTO Type | 540 |
Mid PTO | independent |
Mid PTO Type | 2000 |
Front PTO | optional |
Front PTO Type | 2000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 54.5 inches
138 cm |
Weight | 915 lbs
415 kg |
Front tire | 18x7.00-8 |
Rear tire | 26x10.50-12 |
Full dimensions and tires ...  | |
John Deere X724 attachments | |
|---|---|
48" mid-mount mower deck | |
54" mid-mount mower deck | |
62" mid-mount mower deck | |
Attachment details ...  |
X724 Serial Number Location | |
|---|---|
 | |
On the center-right of main tractor frame, just behind hydraulic couplers. |
X724 Serial Numbers | |
|---|---|
2006 | 010001 |
2007 | 020001 |
2008 | 030001 |
2009 | 040001 |
2010 | 050001 |
2011 | 060001 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 20 |
| 40 (optional) |
Battery CCA | 340 |
Battery volts | 12 |
References | |
|---|---|
 | |
Select Series Tractors published in 2007, by John Deere | |
Select Series Tractors published in 2009, by John Deere | |
Select Series Tractors published in 2012, by John Deere | |
Commercial & Consumer Equipment Purchasing Guide published in 2007, by John Deere | |
Riding Lawn Equipment Attachments & Accessories published in 2011, by John Deere |
 | |
|---|---|
