kubota l245

1976 - 1985

L Series

Compact Utility tractor

L Series

Compact Utility tractor

Manufacturer

Kubota

Compact Utility tractor

Built in Japan

Original price was $4,000 in 1977

L245

2WD

L245DT

4WD

L245H

high clearance

Kubota 1.1L 3-cyl diesel

8-speed gear

Engine

25 hp 18.6 kW

Drawbar (claimed)

17.8 hp 13.3 kW

PTO (claimed)

22 hp 16.4 kW

Drawbar (tested)

18.10 hp 13.5 kW

PTO (tested)

22.35 hp 16.7 kW

Two- or four-wheel drive

Manual steering

Differential mechanical wet disc brakes

Open operator station. Two-post ROPS optional.

Fuel

6 gal 22.7 L

Hydraulic system

8.7 gal 32.9 L

Type

open center

Capacity

8.7 gal 32.9 L

Pressure

2000 psi 137.9 bar

Total flow

3.7 gpm 14.0 lpm

Rear Type

I

Rear lift (at ends)

1540 lbs 698 kg

Rear PTO

independent

Rear PTO Type

540/700/1000

Wheelbase

63 inches (2WD) 160 cm



61.2 inches (4WD) 155 cm

Weight

1825 to 2382 pounds

Front tire

5.00-15

Rear tire

11.2-24

snowblower

front-end loader

backhoe

Ground

negative

Battery volts

12
