kubota l295
 | 1978 - 1982
Compact Utility tractor | 1978 - 1982 | Compact Utility tractor |
|---|---|---|---|
1978 - 1982 | |||
Compact Utility tractor | |||
1978 - 1982 | |
|---|---|
Compact Utility tractor |
Production | |
|---|---|
Manufacturer | Kubota |
Compact Utility tractor | |
Variants | |
|---|---|
L295F | 2WD |
L295DT | 4WD |
Kubota L295 Engine | |
|---|---|
Kubota 1.3L 3-cyl diesel | |
Fuel tank | 9.2 gal
34.8 L |
Engine details ...  | |
Kubota L295 Transmission | |
|---|---|
8-speed gear | |
Transmission details ...  |
Kubota L295 Power | |
|---|---|
Engine | 30 hp
22.4 kW |
PTO (claimed) | 26 hp
19.4 kW |
Drawbar (tested) | 21.09 hp
15.7 kW |
PTO (tested) | 26.46 hp
19.7 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Final drives | planetary |
Manual steering | |
Differential mechanical wet disc brakes | |
Two-post fixed ROPS. | |
Photos | |
|---|---|
 | |
Kubota L295 photos...  |
Hydraulics | |
|---|---|
Type | open center |
Pump flow | 5.6 gpm
21.2 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Power Take-off (PTO) | |
|---|---|
Rear PTO | live |
Rear PTO Type | 540/700/1000 |
Dimensions & Tires | |
|---|---|
2WD Wheelbase | 65 inches
165 cm |
4WD Wheelbase | 65.4 inches
166 cm |
Weight | 2304 to 2895 pounds |
Front tire | 5.00-15 |
2WD Rear tire | 12.4-24 |
Full dimensions and tires ...  | |
Kubota L295 attachments | |
|---|---|
front-end loader | |
backhoe | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Model L-2773 Front Loader published in 1980, by Kubota | |
Tractors and Excavators published in 1981, by Kubota | |
Kubota Tractors Diesel L295/L305/L345 published in 1981 |
