kubota l3010
 | 1998 - 2002
Grand L10 SeriesCompact Utility tractor | 1998 - 2002 | Grand L10 Series | Compact Utility tractor |
|---|---|---|---|---|
1998 - 2002 | ||||
Grand L10 Series | ||||
Compact Utility tractor | ||||
1998 - 2002 | |
|---|---|
Grand L10 Series | |
Compact Utility tractor |
Production | |
|---|---|
Manufacturer | Kubota |
Compact Utility tractor | |
Variants | |
|---|---|
L3010F | 2WD Gear |
L3010DT | 4WD Gear |
L3010GST | 4WD Glide Shift |
L3010HST | 4WD Hydro |
Kubota L3010 Engine | |
|---|---|
Kubota 1.5L 3-cyl diesel | |
Engine details ...  |
Kubota L3010 Transmissions | |
|---|---|
8-speed mechanical shuttle | |
hydrostatic | |
8-speed automatic fully synchronized | |
16-speed creeper | |
Transmission details ...  |
Kubota L3010 Power | |
|---|---|
Engine (gross) | 32.1 hp
23.9 kW |
Engine (net) | 30.4 hp
22.7 kW |
Gear PTO (claimed) | 25.5 hp
19.0 kW |
Hydro PTO (claimed) | 24 hp
17.9 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Steering | hydrostatic power |
Wet disc brakes | |
Two-post ROPS. | |
Photos | |
|---|---|
 | |
Kubota L3010 photos...  |
Capacity | |
|---|---|
Fuel | 9.2 gal
34.8 L |
Hydraulic system | 10.3 gal
39.0 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 10.3 gal
39.0 L |
Pump flow | 7.0 gpm
26.5 lpm |
Steering flow | 4.7 gpm
17.8 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Control | position control and optional draft control |
Rear lift (at 24"/610mm) | 2,200 lbs
997 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | live |
Rear PTO Type | 540 (1.375) |
Mid PTO | semi-independent |
Mid PTO Type | 2000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 65.7 inches
166 cm |
Weight | 2700 to 2745 pounds |
Front tire | 5.00-15 |
Rear tire | 12.4-24 (2WD) |
Full dimensions and tires ...  | |
Kubota L3010 attachments | |
|---|---|
72" mid-mount mower deck | |
snowblower | |
blade | |
front-end loader | |
backhoe | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 40 |
Battery CCA | 520 |
Battery volts | 12 |
References | |
|---|---|
 | |
1999 Products published by Kubota | |
L3010/L3410/L3710/L4310 published in 1999, by Kubota | |
L3010/L3410/L3710/L4310 published in 1999, by Kubota | |
L3010/L3410/L3710/L4310/L4610 published in 2000, by Kubota |
