kubota l3450
 | 1990 - 1993
L50 SeriesCompact Utility tractor | 1990 - 1993 | L50 Series | Compact Utility tractor |
|---|---|---|---|---|
1990 - 1993 | ||||
L50 Series | ||||
Compact Utility tractor | ||||
1990 - 1993 | |
|---|---|
L50 Series | |
Compact Utility tractor |
Production | |
|---|---|
Manufacturer | Kubota |
Compact Utility tractor | |
Kubota L3450 Engine | |
|---|---|
Kubota 1.9L 4-cyl diesel | |
Engine details ...  |
Kubota L3450 Transmissions | |
|---|---|
8-speed mechanical shuttle | |
8-speed | |
Transmission details ...  |
Kubota L3450 Power | |
|---|---|
Engine (gross) | 36.7 hp
27.4 kW |
PTO (claimed) | 30 hp
22.4 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Differential lock | mechanical rear lock |
Steering | power |
Wet disc brakes | |
Two-post ROPS. Optional canopy. | |
Photos | |
|---|---|
 | |
Kubota L3450 photos...  |
Capacity | |
|---|---|
Fuel | 7.7 gal
29.1 L |
Hydraulic system | 7.5 gal
28.4 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 7.5 gal
28.4 L |
Pressure | 2490 psi
171.7 bar |
Pump flow | 8.2 gpm
31.0 lpm |
Tractor hitch | |
|---|---|
Rear Type | 1 |
Control | position control with optional draft control |
Rear lift (at ends) | 2,645 lbs
1199 kg |
Rear lift (at 24"/610mm) | 2,050 lbs
929 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | transmssion |
| live (optional) |
Rear PTO Type | 540/1000 (1.375) |
Mid PTO | optional |
Mid PTO Type | 1080/2000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 68.3 inches
173 cm |
Weight | 2610 to 2900 pounds |
Front tire | 5.00-15 |
Rear tire | 12.4-24 (2WD) |
Full dimensions and tires ...  | |
Kubota L3450 attachments | |
|---|---|
72" mid-mount mower deck | |
snowblower | |
blade | |
front-end loader | |
backhoe | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Battery CCA | 447 |
Battery volts | 12 |
References | |
|---|---|
 | |
Backhoes published in 1992, by Kubota | |
Backhoes published in 1994, by Kubota | |
Mid-Mount Mowers B/L Series published in 1994, by Kubota* | |
Front Loaders B, L and M-Series published in 1994, by Kubota* | |
Product Catalog published in 1990, by Kubota | |
Diesel Tractors L2350DT, L2950DT, L3450DT and L3650T/DT published in 1991, by Kubota | |
Diesel Tractors L2350/L2650/L2950/L3450/L3650 published in 1994, by Kubota | |
Operator's Manual Models L2650 - L2950 - L3450 - L3650 (35080-19713) published in 2002 | |
New Product Guide L2650/L2950/L3450/L3650 published in 1990, by Kubota | |
*Publication contains known errors. |
