kubota m108s

2007 - 2014

Row-Crop tractor

Row-Crop tractor

Manufacturer

Kubota

Row-Crop tractor

Original price

$36,542 (2011)

M108X

Intelli-Shift

M108SDSL

low-profile

M108SH

2WD ROPS 16-speed

M108SDSF

2WD ROPS 32-speed

M108SHD

4WD ROPS 16-speed

M108SDS

4WD ROPS 32-speed

M108SHC

2WD cab 16-speed

M108SHDC

4WD cab 16-speed

M108SDSC

4WD cab 32-speed

Kubota 3.8L 4-cyl diesel

16-speed partially synchronized

32-speed partial power shift

24-speed partially synchronized

48-speed partial power shift

Engine (net)

108 hp 80.5 kW

PTO (claimed)

96 hp 71.6 kW

PTO (tested)

103.17 hp 76.9 kW

Two- or four-wheel drive

Differential lock

mechanical rear or front-and-rear (4WD) (2WD)

Steering

hydrostatic power

Hydraulic wet disc brakes

Two-post foldable ROPS. Cab with heat and air-conditioning optional.

Fuel

46.2 gal 174.9 L

Hydraulic system

16.6 gal 62.8 L

Front axle

11.1 qts 10.5 L

Type

open center

Capacity

16.6 gal 62.8 L

Pressure

2844 psi 196.1 bar

Valves

1 to 3

Pump flow

17.2 gpm 65.1 lpm

Total flow

29.3 gpm 110.9 lpm

Steering flow

12.1 gpm 45.8 lpm

Rear Type

II

Rear lift (at ends)

5,560 lbs 2522 kg

Rear lift (at 24"/610mm)

4,630 lbs 2100 kg



7,490 lbs (optional) 3397 kg

Rear PTO

independent

Rear PTO Type

540 (1.375)



540/1000 (optional)

Engine RPM

540@2205

Weight

6349 to 8576 pounds

Front tire

10.00-16

Rear tire

18.4-34 (2WD)

front-end loader

Ground

negative

Charging system

alternator

Charging amps

45 (ROPS)



80 (cab)

Battery CCA

900

Battery volts

12

Battery Group

negative
