kubota m4950

1983 - 1993

M50 Series

Utility tractor

M50 Series

Utility tractor

Manufacturer

Kubota

Utility tractor

Built in Japan

M4950F

2WD

M4950DT

4WD

Kubota 2.8L 6-cyl diesel

12-speed fully synchronized

Engine (net)

51 hp 38.0 kW

PTO (claimed)

47 hp 35.0 kW

Drawbar (tested)

40.25 hp 30.0 kW

PTO (tested)

49.57 hp 37.0 kW

Two- or four-wheel drive

Differential lock

mechanical rear

Power steering

Differential mechanical wet disc brakes

Four-post ROPS. Cab optional with air-conditioning.

Fuel

18.5 gal 70.0 L

Hydraulic system

12.7 gal 48.1 L

Type

open center

Capacity

12.7 gal 48.1 L

Pressure

2630 psi 181.3 bar

Valves

1 or 2

Total flow

9.25 gpm 35.0 lpm

Rear Type

II/I

Rear lift (at ends)

3968 lbs 1799 kg

Rear lift (at 24"/610mm)

3307 lbs 1500 kg

Rear PTO

independent

Rear PTO Type

540

Engine RPM

540@2194

2WD Wheelbase

80.9 inches 205 cm

4WD Wheelbase

82.3 inches 209 cm

Weight

4762 to 5800 pounds

Front tire

6.00-16

2WD Rear tire

14.9-28

front-end loader

Charging system

alternator

Charging amps

65 (with cab)

Battery volts

12

Battery AH

300

Front Loaders published in 1988, by Kubota

Front Loaders B, L and M-Series published in 1994, by Kubota*

Product Catalog published in 1990, by Kubota

M-Series published in 1985, by Kubota

*Publication contains known errors.
