kubota m7040

2007 - 2013

Model year 2007-20092010-2013

Utility tractor

Model year 2007-20092010-2013

Utility tractor

Manufacturer

Kubota

Utility tractor

M7040SU

economy model

M7040HDN

narrow chassis

M7040F

2WD ROPS sync-shuttle

M7040FC

2WD cab sync-shuttle

M7040DT

4WD ROPS sync-shuttle

M7040HD

4WD ROPS hyd-shuttle

M7040DTC

4WD cab sync-shuttle

M7040HDC

4WD cab hyd-shuttle

Kubota 3.3L 4-cyl diesel

8-speed partially synchronized

8-speed power shuttle

Engine (net)

67 hp 50.0 kW

PTO (claimed)

62 hp 46.2 kW

Two- or four-wheel drive

Differential lock

mechanical rear

Power steering

Wet disc brakes

Two-post ROPS with optional canopy. Ultra Grand Cab optional with heat and air-conditioning

ROPS, 29.1 Cab} Fuel

18.5 gal 70.0 L

Hydraulic system

10.6 gal 40.1 L

Front axle

8.5 qts 8.0 L

Type

open center

Capacity

10.6 gal 40.1 L

Pressure

2770 psi 191.0 bar

Valves

1 to 3

Pump flow

11 gpm 41.6 lpm

Total flow

17.2 gpm 65.1 lpm

Steering flow

6.1 gpm 23.1 lpm

Rear Type

II

Rear lift (at ends)

4200 lbs 1905 kg

Rear lift (at 24"/610mm)

3307 lbs 1500 kg

Rear PTO

independent

Rear PTO Type

540 (1.375)

Engine RPM

540@2295

Wheelbase

80.7 inches (4WD ROPS) 204 cm



82.1 inches (2WD ROPS) 208 cm



83.1 inches (4WD cab) 211 cm



84.4 inches (2WD cab) 214 cm

Weight

4675 to 5470 pounds

Front tire

7.50-16

Rear tire

16.9-30 (2WD)

front-end loader

backhoe

Ground

negative

Charging system

alternator

Charging amps

45 (ROPS)



60 (cab)



80 (optional)

Battery CCA

900

Battery volts

12

M5040/M6040/M7040/M8540/M9540 published in 2005, by Kubota

New Product Guide M-Series Tractors published in 2005, by Kubota
