kubota m7 151
 | 2015 - 2018
M7-1 SeriesRow-Crop tractor | 2015 - 2018 | M7-1 Series | Row-Crop tractor |
|---|---|---|---|---|
2015 - 2018 | ||||
M7-1 Series | ||||
Row-Crop tractor | ||||
2015 - 2018 | |
|---|---|
M7-1 Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | Kubota |
Row-Crop tractor | |
Built in Bierne, France | |
Kubota M7-151 Engine | |
|---|---|
Kubota 6.1L 4-cyl diesel | |
Fuel tank | 87 gal
329.3 L |
Exhaust fluid (DEF) | 10 gal
37.9 L |
Engine details ...  | |
Kubota M7-151 Transmissions | |
|---|---|
24-speed partial power shift | |
continuously variable transmission | |
Transmission details ...  |
Kubota M7-151 Power | |
|---|---|
Engine (gross) | 148 hp
110.4 kW |
Engine (max) | 168 hp
125.3 kW |
PTO (claimed) | 120 hp
89.5 kW |
Drawbar (tested) | 122.69 hp
91.5 kW |
PTO (tested) | 144.59 hp
107.8 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Cab standard. |
Photos | |
|---|---|
 | |
Kubota M7-151 photos...  |
Hydraulics | |
|---|---|
Type | open center *Standard |
| closed center load sensing *Premium |
Pump flow | 21 gpm*Standard
79.5 lpm |
| 29 gpm*Premium
109.8 lpm |
Tractor hitch | |
|---|---|
Rear Type | III |
Control | lower-link electronic draft sensing |
Rear lift (at ends) | 14770 lbs
6699 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/540E/1000/1000E |
Front PTO | independent OptOptional |
Front PTO Type | 1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 107 inches
271 cm |
Weight | 15097 lbs
6847 kg |
Front tire | 14.9R28 |
Rear tire | 18.4R38 |
Full dimensions and tires ...  | |
Kubota M7-151 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 150 |
| 200 OptOptional |
Battery volts | 12 |
References | |
|---|---|
 | |
M7 Series published in 2016, by Kubota |
