kubota m8 201
 | 2020 -
M8 SeriesRow-Crop tractorVersatile built | 2020 - | M8 Series | Row-Crop tractor | Versatile built |
|---|---|---|---|---|---|
2020 - | |||||
M8 Series | |||||
Row-Crop tractor | |||||
Versatile built | |||||
2020 - | |
|---|---|
M8 Series | |
Row-Crop tractor | |
Versatile built |
Production | |
|---|---|
Distributor | Kubota |
Manufacturer | Versatile |
Row-Crop tractor | |
Built in Winnigpeg, Manitoba, Canada | |
Kubota M8-201 Engine | |
|---|---|
Cummins 6.7L 6-cyl diesel | |
Fuel tank | 99 gal
374.7 L |
Exhaust fluid (DEF) | 9 gal
34.1 L |
Engine details ...  | |
Kubota M8-201 Transmissions | |
|---|---|
30-speed six-speed power shift | |
continuously-variable transmission | |
Transmission details ...  |
Kubota M8-201 Power | |
|---|---|
Engine | 200 hp
149.1 kW |
PTO (claimed) | 159 hp
118.6 kW |
Drawbar (tested) | 164.55 hp
122.7 kW |
PTO (tested) | 179.86 hp
134.1 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Trailer brakes | hydraulic OptOptional |
Cab standard with air-conditioning. | |
Photos | |
|---|---|
 | |
Kubota M8-201 photos...  |
Hydraulics | |
|---|---|
Type | closed-center load sensing |
Rear valves | 3 to 5 |
Pump flow | 31.7 gpm
120.0 lpm |
| 42.2 gpmOptOptional
159.7 lpm |
SCV flow | 31.7 gpm
120.0 lpm |
Steering flow | 11.1 gpm
42.0 lpm |
Tractor hitch | |
|---|---|
Rear Type | III/IIIN |
Rear lift (at 24"/610mm) | 12478 lbs
5660 kg |
| 15543 lbsOptOptional
7050 kg |
Front Hitch | IIIN |
Front lift | 8818 lbs
3999 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic |
Rear PTO Type | 540/1000 (1.375) |
| 1000 (1.75) |
Engine RPM | 1000 (1.375) |
Dimensions & Tires | |
|---|---|
Wheelbase | 114 inches
289 cm |
Weight | 19510 lbs
8849 kg |
Full dimensions and tires ...  | |
Kubota M8-201 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
M8 Built Right. Built Ready. published in 2021, by Kubota |
