kubota m9960
 | 2013 - 2016
M60 SeriesUtility tractor | 2013 - 2016 | M60 Series | Utility tractor |
|---|---|---|---|---|
2013 - 2016 | ||||
M60 Series | ||||
Utility tractor | ||||
2013 - 2016 | |
|---|---|
M60 Series | |
Utility tractor |
Production | |
|---|---|
Manufacturer | Kubota |
Utility tractor | |
During the Nebraska performance test, the M9960 was unable to lift the advertised 7275 pounds on the three-point lift. Actual lift was 6192 pounds. | |
Variants | |
|---|---|
M9960HF | 2WD ROPS 8-speed |
M9960HFC | 2WD Cab 8-speed |
M9960HD | 4WD ROPS 8-speed |
M9960HDC | 4WD Cab 8-speed |
M9960HD12 | 4WD ROPS 12-speed |
M9960HDC12 | 4WD Cab 12-speed |
M9960HDC24 | 4WD Cab 24-speed |
Kubota M9960 Engine | |
|---|---|
Kubota 3.8L 4-cyl diesel | |
ROPS Fuel tank | 23.8 gal
90.1 L |
Cab Fuel tank | 29.1 gal
110.1 L |
Engine details ...  | |
Kubota M9960 Transmissions | |
|---|---|
8-speed power shuttle | |
12-speed | |
24-speed 2-speed power shift | |
Transmission details ...  |
Kubota M9960 Power | |
|---|---|
Engine (net) | 100 hp
74.6 kW |
PTO (claimed) | 89 hp
66.4 kW |
PTO (tested) | 91.03 hp
67.9 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Steering | hydrostatic power |
Hydraulic wet disc brakes | |
Two-post foldable ROPS. Optional Ultra Grand Cab with air-conditioning. Optional air-ride seat and AM/FM/CD/MP3 sound system. | |
Photos | |
|---|---|
 | |
Kubota M9960 photos...  |
Hydraulics | |
|---|---|
Valves | 1 to 3 |
ROPS Pump flow | 15.9 gpm
60.2 lpm |
Cab Pump flow | 17 gpm
64.3 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position control and top-link draft sensing |
Rear lift (at 24"/610mm) | 4630 lbs
2100 kg |
| 7275 lbs (optional)
3299 kg |
Rear Arms | telescopic lower link ends |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic |
Rear PTO Type | 540 (1.375 |
| 540/540E (1.375) |
| 540/1000 (1.375) |
Dimensions & Tires | |
|---|---|
ROPS Wheelbase | 90 inches
228 cm |
Cab Wheelbase | 88.6 inches
225 cm |
Weight | 5535 to 6810 pounds |
Front tire | 7.50-18 |
Rear tire | 18.4-30 (2WD) |
Full dimensions and tires ...  | |
Kubota M9960 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
ROPS Charging amps | 45 |
Cab Charging amps | 60 |
Optional Charging amps | 100 |
Battery volts | 12 |
References | |
|---|---|
 | |
M8560/M9960 published in 2012, by Kubota |
