kubota mx5400
 | 2020 -
MX SeriesUtility tractor | 2020 - | MX Series | Utility tractor |
|---|---|---|---|---|
2020 - | ||||
MX Series | ||||
Utility tractor | ||||
2020 - | |
|---|---|
MX Series | |
Utility tractor |
Production | |
|---|---|
Manufacturer | Kubota |
Utility tractor | |
Original price | $22,885 (2021 Gear 2WD ROPS ) |
$37,531 (2021 Hydro 4WD Cab ) | |
Kubota MX5400 Engine | |
|---|---|
Kubota 2.4L 4-cyl diesel | |
Fuel tank | 11.9 gal
45.0 L |
Engine details ...  | |
Kubota MX5400 Transmissions | |
|---|---|
8-speed synchronized shuttle | |
hydrostatic | |
Transmission details ...  |
Kubota MX5400 Power | |
|---|---|
Engine (gross) | 55.5 hp
41.4 kW |
Engine (net) | 53 hp
39.5 kW |
PTO (claimed) | 46.5 hp
34.7 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Differential lock | mechanical rear |
Power steering | |
Mechanical wet disc brakes | |
Two-post fodling ROPS. Cab optional with air-conditioning. | |
Photos | |
|---|---|
 | |
Kubota MX5400 photos...  |
Hydraulics | |
|---|---|
Type | open center |
Valves | 3 OptOptional |
Pump flow | 9.5 gpm
36.0 lpm |
Steering flow | 4.9 gpm
18.5 lpm |
Tractor hitch | |
|---|---|
Rear Type | II/I |
Control | position control with optional draft control |
Rear lift | 2310 lbs
1047 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic wet disc |
Rear PTO Type | 540 (1.375) |
Dimensions & Tires | |
|---|---|
Wheelbase | 74.6 inches
189 cm |
Weight | 3474 to 4268 pounds |
Front tire | 7.5L-15 |
2WD Rear tire | 14.9-26 |
Full dimensions and tires ...  | |
Kubota MX5400 attachments | |
|---|---|
front-end loader | |
backhoe | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
ROPS Charging amps | 45 |
Cab Charging amps | 60 |
Battery volts | 12 |
References | |
|---|---|
 | |
Diesel Tractor MX5400/MX6000 published in 2019, by Kubota |
