massey ferguson 1547

2005 - 2008

1500 Series

Compact Utility tractor

Iseki built

1500 Series

Compact Utility tractor

Iseki built

Distributor

Massey Ferguson

Manufacturer

Iseki

Compact Utility tractor

Built in Matsuyama, Japan

Iseki 2.2L 4-cyl diesel

8-speed synchro shuttle

hydrostatic

12-speed power shuttle

12-speed four-speed power shift

Engine (gross)

47 hp 35.0 kW

Gear PTO (claimed)

38 hp 28.3 kW

Hydro PTO (claimed)

36.5 hp 27.2 kW

Two- or four-wheel drive

Wet disc brakes

Two-post folding ROPS. Cab optional with air-conditioning.

Fuel

13.2 gal 50.0 L

Front axle

9 qts 8.5 L

Type

open center

Valves

2 OptOptional

Pump flow

11.6 gpm 43.9 lpm

Total flow

16.5 gpm 62.5 lpm



17.6 gpm (with PowerShuttle) 66.6 lpm

Steering flow

4.9 gpm 18.5 lpm



6 gpm (with PowerShuttle) 22.7 lpm

Rear Type

I

Rear lift (at ends)

3,483 lbs 1579 kg

Rear PTO

independent

Rear PTO Type

540 (1.375)

Mid PTO

independent OptOptional

Mid PTO Type

2000

Wheelbase

75 inches 190 cm

Weight

3597 to 3957 pounds

snowblower

blade

front-end loader

backhoe

Ground

negative

Charging system

alternator

Battery volts

12

MF 1500 Series published in 2005, by Massey Ferguson

MF 1500 Series published in 2006, by Massey Ferguson

1500 Series Compact Tractors published in 2007, by Massey Ferguson
