massey ferguson 1648
 | 2009 - 2013
1600 SeriesCompact Utility tractor | 2009 - 2013 | 1600 Series | Compact Utility tractor |
|---|---|---|---|---|
2009 - 2013 | ||||
1600 Series | ||||
Compact Utility tractor | ||||
2009 - 2013 | |
|---|---|
1600 Series | |
Compact Utility tractor |
Production | |
|---|---|
Manufacturer | Massey Ferguson |
Compact Utility tractor | |
Original price | $21,614 (2009 SyncShuttle ROPS ) |
$29,165 (2009 Hydrostatic Cab ) | |
Massey Ferguson 1648 Engine | |
|---|---|
Iseki 2.2L 4-cyl diesel | |
Fuel tank | 13.2 gal
50.0 L |
Engine details ...  | |
Massey Ferguson 1648 Transmissions | |
|---|---|
8-speed | |
12-speed | |
hydrostatic | |
Transmission details ...  |
Massey Ferguson 1648 Power | |
|---|---|
Engine (gross) | 47.1 hp
35.1 kW |
Engine (net) | 46 hp
34.3 kW |
Gear PTO (claimed) | 38 hp
28.3 kW |
Hydro PTO (claimed) | 36.5 hp
27.2 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | mechanical rear |
Power steering | |
Wet disc brakes | |
Flat operator platform with folding ROPS. Optional cab with heat and air-conditioning. | |
Hydraulics | |
|---|---|
Type | open center |
Valves | 0 to 3 |
Pump flow | 11.6 gpm
43.9 lpm |
Steering flow | 4.9 gpm
18.5 lpm |
| 6 gpm (Power Shuttle)
22.7 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Control | position control |
Rear lift (at ends) | 3483 lbs
1579 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic |
Rear PTO Type | 540 (1.375) |
Mid PTO | independent OptOptional |
Mid PTO Type | 2000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 74.8 inches
189 cm |
Weight | 3715 to 4068 pounds |
Front tire | 9.5x16 |
Rear tire | 13.6x28 |
Full dimensions and tires ...  | |
Massey Ferguson 1648 attachments | |
|---|---|
front-end loader | |
backhoe | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
References | |
|---|---|
 | |
1600/1500 Series Compact Tractors published in 2011, by Massey Ferguson |
