massey ferguson 174s
 | 1986 - 1989
Orchard/Vineyard tractor | 1986 - 1989 | Orchard/Vineyard tractor |
|---|---|---|---|
1986 - 1989 | |||
Orchard/Vineyard tractor | |||
1986 - 1989 | |
|---|---|
Orchard/Vineyard tractor |
Transmission options | |
|---|---|
12-speed partially synchronized | |
20-speed creeper |
Transmission | |
|---|---|
Type | partially synchronized |
Gears | 12 forward and 4 reverse |
Clutch | 279.4mm dry disc |
Oil capacity | 40 qts
37.9 L |
Four synchronized gears in three ranges, plus reverse range. | |
Speeds | |
|---|---|
With 14.9-24 rear tires. | |
 |
Transmission | |
|---|---|
Type | creeper |
Gears | 20 forward and 8 reverse |
Clutch | dry disc |
