massey ferguson 175

1964 - 1975

Row-Crop tractor

Row-Crop tractor

NTTL 897: diesel 12-speed 2WD

NTTL 1020: Perkins gasoline 12-speed 2WD

Diesel 12-speed 2WD May 17 - 29, 1965 Link: Nebraska Tractor Test 897 file

PTO performance

Power at rated engine speed

63.34 hp 47.2 kW

Fuel use

3.8 gal/hour 14.4 l/hour

Power at rated PTO speed

55.46 hp 41.4 kW

Fuel use

3.3 gal/hour 12.5 l/hour

Drawbar performance

Max power

53.51 hp 39.9 kW

Fuel use

3.7 gal/hour 14.0 l/hour

Gear 1H Low used for power test.

Max pull

7,109 lbs 3224 kg

Gear 2L Hi used for pull test.

Perkins gasoline 12-speed 2WD September 11 - 25, 1969 Link: Nebraska Tractor Test 1020 file

PTO performance

Power at rated engine speed

61.89 hp 46.2 kW

Fuel use

5.6 gal/hour 21.2 l/hour

Power at rated PTO speed

58.06 hp 43.3 kW

Fuel use

5.0 gal/hour 18.9 l/hour

Drawbar performance

Max power

48.3 hp 36.0 kW

Fuel use

4.9 gal/hour 18.5 l/hour

Gear 1H Low used for power test.

Max pull

6,848 lbs 3106 kg

Gear 2L Hi used for pull test.
