massey ferguson 5475
 | 2008 - 2013
5400 SeriesUtility tractor | 2008 - 2013 | 5400 Series | Utility tractor |
|---|---|---|---|---|
2008 - 2013 | ||||
5400 Series | ||||
Utility tractor | ||||
2008 - 2013 | |
|---|---|
5400 Series | |
Utility tractor |
Production | |
|---|---|
Manufacturer | Massey Ferguson |
Utility tractor | |
Built in Beauvais, France | |
Original price | $62,981 (2009 Cab 2WD ) |
$69,481 (2009 Cab 4WD ) | |
Massey Ferguson 5475 Engine | |
|---|---|
Perkins 6.6L 6-cyl diesel | |
Fuel tank | 38 gal
143.8 L |
| 55 gal (optional)
208.2 L |
Engine details ...  | |
Massey Ferguson 5475 Transmission | |
|---|---|
16-speed partial power shift | |
Transmission details ...  |
Massey Ferguson 5475 Power | |
|---|---|
Engine (gross) | 135 hp
100.7 kW |
PTO (claimed) | 110 hp
82.0 kW |
Drawbar (tested) | 101.2 hp
75.5 kW |
PTO (tested) | 133.6 hp
99.6 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Final drives | inboard planetary |
Differential lock | electro-hydraulic rear |
Power steering | |
Hydraulic wet disc brakes | |
Trailer brakes | hydraulic OptOptional |
Cab standard with air-conditioning. | |
Photos | |
|---|---|
 | |
Massey Ferguson 5475 photos...  |
Hydraulics | |
|---|---|
Type | open center |
| closed center OptOptional |
Pump flow | 15 gpm (open center)
56.8 lpm |
| 26 gpm (open- optional)
98.4 lpm |
| 29 gpm (closed center)
109.8 lpm |
Tractor hitch | |
|---|---|
Rear Type | III/II |
Control | electronic draft sensing |
Rear lift (at 24"/610mm) | 9189 lbs
4168 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Front PTO | independent OptOptional |
Front PTO Type | 1000 (1.375) |
Dimensions & Tires | |
|---|---|
Wheelbase | 112.3 inches
285 cm |
Weight | 11195 to 11905 pounds |
Front tire | 10.00-16 |
2WD Rear tire | 460/85R34 |
Full dimensions and tires ...  | |
Massey Ferguson 5475 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 80 |
| 120 OptOptional |
Battery CCA | 775 |
Battery volts | 12 |
References | |
|---|---|
 | |
5400 Series published in 2010, by Massey Ferguson |
