massey ferguson 6490
 | 2004 - 2012
Model year 2004-20072008-2012
6400 SeriesRow-Crop tractor | 2004 - 2012 | Model year 2004-20072008-2012 | 6400 Series | Row-Crop tractor |
|---|---|---|---|---|---|
2004 - 2012 | |||||
Model year 2004-20072008-2012 | |||||
6400 Series | |||||
Row-Crop tractor | |||||
2004 - 2012 | |
|---|---|
Model year 2004-20072008-2012 | |
6400 Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | Massey Ferguson |
Row-Crop tractor | |
Built in Beauvais, France | |
Variants | |
|---|---|
6490 | Dyna-6 |
7490 | Dyna-VT |
Massey Ferguson 6490 Engine | |
|---|---|
Sisu 6.6L 6-cyl diesel | |
Fuel tank | 93.8 gal
355.0 L |
Engine details ...  | |
Massey Ferguson 6490 Transmissions | |
|---|---|
24-speed six-speed power shift | |
32-speed creeper | |
Transmission details ...  |
Massey Ferguson 6490 Power | |
|---|---|
Engine | 168 hp
125.3 kW |
PTO (claimed) | 140 hp
104.4 kW |
Drawbar (tested) | 121.5 hp
90.6 kW |
PTO (tested) | 145.2 hp
108.3 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Independent hydraulic wet disc brakes | |
Cab standard with air-conditioning. |
Photos | |
|---|---|
 | |
Massey Ferguson 6490 photos...  |
Hydraulics | |
|---|---|
Type | closed center PFC |
Pressure | 2900 psi
200.0 bar |
Valves | 3 to 5 |
Total flow | 29 gpm
109.8 lpm |
Tractor hitch | |
|---|---|
Rear Type | II/IIIN |
Rear lift (at 24"/610mm) | 15,240 lbs
6912 kg |
Front Hitch | optional |
Front lift | 7,000 lbs
3175 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/540E/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 120.1 inches (2WD)
305 cm |
| 118.6 inches (4WD)
301 cm |
Weight | 14275 to 15465 pounds |
Front tire | 14.9R28 |
Rear tire | 18.4R38 |
Full dimensions and tires ...  | |
Massey Ferguson 6490 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 120 |
Battery volts | 12 |
