massey ferguson 699
![]() | 1984 - 1986
Série 600 Tracteur utilitaire | 1984 - 1986 | Série 600 | Tracteur utilitaire |
---|---|---|---|---|
1984 - 1986 | ||||
Série 600 | ||||
Tracteur utilitaire |
1984 - 1986 | |
---|---|
Série 600 | |
Tracteur utilitaire |
Production | |
---|---|
Fabricant | Massey Ferguson |
Tracteur utilitaire | |
Construit à Beauvais, France | |
Le prix original était de 35 000 $ en 1986 |
Variantes | |
---|---|
699 | 2WD |
699-4 | 4x4 |
Moteur Massey Ferguson 699 | |
---|---|
Perkins 5.8L 6-cyl diesel | |
Réservoir de carburant | 38,3 gal
145,0 L |
Détails du moteur ... ![]() |
Transmission Massey Ferguson 699 | |
---|---|
12 vitesses synchronisées | |
Détails de la transmission... ![]() |
Massey Ferguson 699 Power | |
---|---|
PTO (déclaré) | 85 ch
63,4 kW |
Attelage (testé) | 69,33 ch
51,7 kW |
PTO (testé) | 85,79 ch
64,0 kW |
Détails du test de performance ... ![]() |
Mécanique | |
---|---|
Transmission à deux ou quatre roues | |
Finales | planétaire |
Verrouillage du différentiel | mécanique arrière |
Direction assistée | |
Freins à disque humide hydrauliques | |
ROPS à quatre poteaux. Cabine disponible avec climatisation. |
Photos | |
---|---|
![]() | |
Photos Massey Ferguson 699... ![]() |
Hydraulique | |
---|---|
Type | centre ouvert |
Pression | 2500 psi
172,4 bar |
Vannes | 2 ou 3 |
Débit de la pompe | 10 gpm
37,9 lpm |
| 7 gpm (pompe attelage)
26,5 lpm |
Débit total | 17 gpm
64,3 lpm |
Attelage de tracteur | |
---|---|
Type arrière | II |
Levage arrière (à 24"/610mm) | 5259 lbs
2385 kg |
Prise de Puissance (PTO) | |
---|---|
Prise de puissance arrière | indépendant |
Type de prise de force arrière | 540/1000 |
Tours par minute du moteur | 540@1900 |
| 1000@1900 |
Dimensions et Pneumatiques | |
---|---|
Empattement | 101,6 pouces
258 cm |
Poids | 8304 à 10325 livres |
Pneus avant | 10.00-16 |
Pneus arrière 2WD | 18,4-34 |
Dimensions complètes et pneus ... ![]() |
Électrique | |
---|---|
Sol | négatif |
Système de charge | alternateur |
Ampères de charge | 55 |
Volts de la batterie | 12 |
Références | |
---|---|
![]() | |
699 publié en 1983, par Massey Ferguson | |
Manuel d'information produit Tracteur MF 699 publié en 1984, par Massey Ferguson |
