massey ferguson 7614
 | 2013 - 2014
7600 SeriesRow-Crop tractor | 2013 - 2014 | 7600 Series | Row-Crop tractor |
|---|---|---|---|---|
2013 - 2014 | ||||
7600 Series | ||||
Row-Crop tractor | ||||
2013 - 2014 | |
|---|---|
7600 Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | Massey Ferguson (a part of AGCO) |
Row-Crop tractor | |
Built in Beauvais, France | |
Massey Ferguson 7614 Engine | |
|---|---|
Sisu 6.6L 6-cyl diesel | |
Engine details ...  |
Massey Ferguson 7614 Transmission | |
|---|---|
16-speed four-speed power shift | |
Transmission details ...  |
Massey Ferguson 7614 Power | |
|---|---|
Engine (net) | 130 hp
96.9 kW |
PTO (claimed) | 110 hp
82.0 kW |
Drawbar (tested) | 100.6 hp
75.0 kW |
PTO (tested) | 135.6 hp
101.1 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Four-wheel drive | |
Final drives | inboard planetary |
Differential lock | electro-hydraulic standard |
Power steering | |
Hydraulic wet disc brakes | |
Trailer brakes | hydraulic (optional) |
| pneumatic (optional) |
Cab standard. Optional hydraulic OptiRide cab suspension. AGCOCOMMAND (optional); Auto-Guide 3000 (optional) | |
Photos | |
|---|---|
 | |
Massey Ferguson 7614 photos...  |
Capacity | |
|---|---|
Fuel | 82 gal
310.4 L |
Exhaust fluid (DEF) | 8 gal
30.3 L |
Hydraulic system | 26.4 gal
99.9 L |
Hydraulics | |
|---|---|
Type | closed-center load sensing (CCLS) |
| open center OptOptional |
Capacity | 26.4 gal
99.9 L |
Pressure | 2900 psi
200.0 bar |
Valves | 3 (mechanical) |
| 4 (2 mech, 2 elec) |
| 4 (electric) |
SCV flow | 24.3 gpm
92.0 lpm |
Total flow | 29 gpm
109.8 lpm |
Tractor hitch | |
|---|---|
Rear Type | III |
Control | electronic lower link draft sensing |
Rear lift (at ends) | 9800 lbs
4445 kg |
Front Hitch | optional |
Drawbar | Cat. II with drop pin |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic |
Rear PTO Type | 540/1000 (1.375) |
| 540/540E/1000 (1.375) |
| 540/540E/1000/1000E (1.375) |
Engine RPM | 540@1980 |
| 540E@1533 |
| 1000@2030 |
| 1000E@1572 |
Dimensions & Tires | |
|---|---|
Wheelbase | 113.1 inches
287 cm |
Weight | 15060 lbs
6831 kg |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 120 |
| 175 (option) |
| 240 (dual 120 option) |
Batteries | 2 |
Battery volts | 12 |
References | |
|---|---|
 | |
7600 Series published in 2013, by Massey Ferguson |
