massey harris 20
 | 1946 - 1948
Row-Crop tractor | 1946 - 1948 | Row-Crop tractor |
|---|---|---|---|
1946 - 1948 | |||
Row-Crop tractor | |||
1946 - 1948 | |
|---|---|
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | Massey-Harris |
Row-Crop tractor | |
Built in Racine, Wisconsin, USA | |
Original price was $1,500 in 1948 | |
Variants | |
|---|---|
20 RC | row-crop |
20 STD | standard tread |
Massey-Harris 20 Engines | |
|---|---|
Continental 2.0L 4-cyl gasoline | |
Continental 2.3L 4-cyl kerosene | |
Engine details ...  |
Massey-Harris 20 Transmission | |
|---|---|
4-speed gear | |
Transmission details ...  |
Massey-Harris 20 Power | |
|---|---|
Belt (claimed) | 31 hp
23.1 kW |
Plows | 2 |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Photos | |
|---|---|
 | |
Massey-Harris 20 photos...  |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 550 |
Dimensions & Tires | |
|---|---|
Wheelbase | 83 inches
210 cm |
Weight | 2700 lbs
1224 kg |
Front tire | 4.00x15 |
Rear tire | 9.00x32 |
Full dimensions and tires ...  | |
20 Serial Numbers | |
|---|---|
1946 | 1001 (gas) |
1947 | 1580 (gas) |
1948 | 3584 (gas) |
1947 | 1001 (kerosene) |
1948 | 1354 (kerosene) |
FAQ: How to read a serial number table. | |
References | |
|---|---|
 | |
Tractors published in 1946, by Massey-Harris |
