mccormick deering t 35
 | 1937 - 1939
Agricultural Crawler tractor | 1937 - 1939 | Agricultural Crawler tractor |
|---|---|---|---|
1937 - 1939 | |||
Agricultural Crawler tractor | |||
1937 - 1939 | |
|---|---|
Agricultural Crawler tractor |
Production | |
|---|---|
Manufacturer | McCormick-Deering (a part of International Harvester) |
Agricultural Crawler tractor | |
Total built | 5,586 |
Variants | |
|---|---|
T-35 | gasoline |
TD-35 | diesel |
McCormick-Deering T-35 Engines | |
|---|---|
International Harvester 4.6L 6-cyl gasoline | |
International Harvester 4.6L 6-cyl distillate | |
Fuel tank | 40 gal
151.4 L |
Aux. fuel | 1.25 gal
4.7 L |
Engine details ...  | |
McCormick-Deering T-35 Transmission | |
|---|---|
4-speed gear | |
Transmission details ...  |
McCormick-Deering T-35 Power | |
|---|---|
Drawbar (claimed) | 29 hp
21.6 kW |
Belt (claimed) | 39 hp
29.1 kW |
Drawbar (tested) | 35.9 hp
26.8 kW |
Belt (tested) | 44.4 hp
33.1 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Drive | crawler |
Dimensions & Tracks | |
|---|---|
Weight | 10,050 lbs
4558 kg |
13-inch tracks | |
Full dimensions and tracks ...  | |
T-35 Serial Numbers | |
|---|---|
Location: | Seat, right side |
References | |
|---|---|
 | |
International Tractors - The Line That Offers You A Choice published in 1933, by International Harvester |
