new holland 2120
 | 1996 - 2000
Twenty Compact SeriesCompact Utility tractorShibaura built | 1996 - 2000 | Twenty Compact Series | Compact Utility tractor | Shibaura built |
|---|---|---|---|---|---|
1996 - 2000 | |||||
Twenty Compact Series | |||||
Compact Utility tractor | |||||
Shibaura built | |||||
1996 - 2000 | |
|---|---|
Twenty Compact Series | |
Compact Utility tractor | |
Shibaura built |
Series map: 1920212033.3hp42.6hp2120↓ 1987-1995
Note: the New Holland model 2120 is the same as the Ford 2120. The following data is from the 2120 listing. |
|---|
Production | |
|---|---|
Distributor | New Holland |
Manufacturer | Shibaura |
Compact Utility tractor | |
Built in Japan | |
Original price | $21,200 |
New Holland 2120 Engine | |
|---|---|
Shibaura 2.3L 4-cyl diesel | |
Fuel tank | 11.1 gal
42.0 L |
Engine details ...  | |
New Holland 2120 Transmissions | |
|---|---|
12-speed gear | |
12-speed power shuttle | |
Transmission details ...  |
New Holland 2120 Power | |
|---|---|
Engine (gross) | 42.6 hp
31.8 kW |
Engine (net) | 40 hp
29.8 kW |
PTO (claimed) | 34.5 hp
25.7 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Wet disc brakes | |
Two-post ROPS. Optional FOPS canopy. |
Photos | |
|---|---|
 | |
New Holland 2120 photos...  |
Hydraulics | |
|---|---|
Type | open center |
Pump flow | 9.3 gpm
35.2 lpm |
Total flow | 12.1 gpm
45.8 lpm |
Steering flow | 2.8 gpm
10.6 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Control | draft control |
Rear lift (at 24"/610mm) | 2574 lbs
1167 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 |
Dimensions & Tires | |
|---|---|
Wheelbase | 74.8 inches
189 cm |
Weight | 3572 to 3858 pounds |
Front tire | 6.00x16 |
2WD Rear tire | 13.6x28 |
Full dimensions and tires ...  | |
New Holland 2120 attachments | |
|---|---|
blade | |
front-end loader | |
backhoe | |
Attachment details ...  |
2120 Serial Numbers | |
|---|---|
Location: | Transmission housing, left side |
1988 | UV21003 |
1989 | UV22274 |
1990 | UV23599 |
1991 | UV24295 |
1992 | UV25141 |
1993 | UV25891 |
1994 | UV26738 |
1995 | UV27935 |
1996 | UV28911 |
1997 | UV29898 |
1998 | UV30679 |
1999 | UV31770 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Compact Diesel Tractors published in 1996, by New Holland | |
North American Buyer's Guide published in 1997, by New Holland |
