new holland 9680
![]() | 1994 - 1995
Série 80Tracteur à quatre roues motrices (4WD)Construit par Versatile | 1994 - 1995 | Série 80 | Tracteur à quatre roues motrices (4WD) | Construction polyvalente |
|---|---|---|---|---|---|
1994 - 1995 | |||||
Série 80 | |||||
Tracteur à quatre roues motrices (4WD) | |||||
Construction polyvalente | |||||
1994 - 1995 | |
|---|---|
Série 80 | |
Tracteur à quatre roues motrices (4WD) | |
Construction polyvalente |
Production | |
|---|---|
Distributeur | New Holland |
Fabricant | Polyvalent |
Tracteur à quatre roues motrices (4WD) | |
Construit à Winnigpeg, Manitoba, Canada | |
Le prix original était de 120 000 $ en 1995 | |
Moteur New Holland 9680 | |
|---|---|
Cummins 14.0L diesel 6-cylindres | |
Détails du moteur ... |
Transmissions New Holland 9680 | |
|---|---|
12 vitesses synchronisées partiellement | |
12 vitesses à puissance intégrale | |
Détails de la transmission... |
New Holland 9680 Power | |
|---|---|
Moteur | 350 ch
261,0 kW |
PTO (déclaré) | 308 ch
229,7 kW |
Mécanique | |
|---|---|
Transmission intégrale | |
Finales | planétaire hors-bord |
Direction assistée articulée | |
Freins à disque hydrauliques | |
Cabine standard avec climatisation. | |
Photos | |
|---|---|
![]() | |
Photos New Holland 9680... |
Capacité | |
|---|---|
Carburant | 245 gal
927,3 L |
Système hydraulique | 15.3 gal
57,9 L |
Hydraulique | |
|---|---|
Type | centre fermée à charge sensible |
Capacité | 15.3 gal
57,9 L |
Pression | 2500 psi
172,4 bar |
Débit de la pompe | 30 gpm
113,6 lpm |
Débit de direction | 30 gpm
113,6 lpm |
Attelage de tracteur | |
|---|---|
Type arrière | IVN |
Contrôle | contrôle électronique de position |
Levage arrière (à 24"/610mm) | 13036 lbs
5913 kg |
Prise de Puissance (PTO) | |
|---|---|
Prise de puissance arrière | indépendant |
Type de prise de force arrière | 1000 (1,75) |
Tours par minute du moteur | 1000@2100 |
Dimensions et Pneumatiques | |
|---|---|
Empattement | 133,1 pouces
338 cm |
Poids | 25198 lbs
11429 kg |
Pneus avant | 20.8x38 |
Pneus arrière | 20.8x38 |
Dimensions complètes et pneus ... | |
Électrique | |
|---|---|
Sol | négatif |
Système de charge | alternateur |
Ampères de charge | 130 |
Batteries | 3 |
CCA de la batterie | 950 |
Volts de la batterie | 12 |
Groupe batterie | 31 |
Références | |
|---|---|
![]() | |
La nouvelle série Versatile 80 publiée en 1994, par Ford | |
Tracteurs 4WD Versatile Série 80 publiés en 1994, par New Holland |
