new holland t4040
 | 2008 - 2011
T4000 SeriesUtility tractor | 2008 - 2011 | T4000 Series | Utility tractor |
|---|---|---|---|---|
2008 - 2011 | ||||
T4000 Series | ||||
Utility tractor | ||||
2008 - 2011 | |
|---|---|
T4000 Series | |
Utility tractor |
Production | |
|---|---|
Manufacturer | New Holland |
Utility tractor | |
Built in Jesi, Italy | |
Variants | |
|---|---|
T4040 | conventional chassis |
T4040F | narrow chassis |
T4040V | ultra-narrow chassis |
Farmall 85C | similar CaseIH model |
New Holland T4040 Engine | |
|---|---|
FPT 4.5L 4-cyl diesel | |
Fuel tank | 21.6 gal
81.8 L |
| 23.2 gal (Deluxe)
87.8 L |
Engine details ...  | |
New Holland T4040 Transmissions | |
|---|---|
12-speed mechanical shuttle | |
16-speed mechanical shuttle | |
16-speed power shuttle | |
Transmission details ...  |
New Holland T4040 Power | |
|---|---|
Engine (gross) | 84 hp
62.6 kW |
PTO (claimed) | 70 hp
52.2 kW |
Drawbar (tested) | 64.0 hp
47.7 kW |
PTO (tested) | 75.4 hp
56.2 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Differential lock | mechanical rear |
Steering | hydrostatic power |
Hydraulic wet disc brakes | |
Platform with ROPS. Cab on deluxe model with heat and air-conditioning. | |
Hydraulics | |
|---|---|
Type | open center |
Pressure | 2,755 psi
190.0 bar |
Valves | 1 to 5 |
Pump flow | 16.1 gpm
60.9 lpm |
Steering flow | 9.4 gpm
35.6 lpm |
Tractor hitch | |
|---|---|
Rear Type | II/I |
Rear lift (at 24"/610mm) | 3962 lbs
1797 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | 280mm mechanical dry disc |
Rear PTO Type | 540 (1.375) |
| 540/1000 (1.375)OptOptional |
Engine RPM | 540@2196 |
Dimensions & Tires | |
|---|---|
Wheelbase | 83.7 inches (4WD)
212 cm |
| 86.0 inches (4WD deluxe)
218 cm |
| 86.7 inches (2WD)
220 cm |
| 89.0 inches (2WD deluxe)
226 cm |
Weight | 5953 to 6944 pounds |
Front tire | 11.2R24 |
Rear tire | 16.9R30 |
Full dimensions and tires ...  | |
New Holland T4040 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 120 |
Battery CCA | 800 |
Battery volts | 12 |
References | |
|---|---|
 | |
T4000 Series Utility Tractors published in 2008, by New Holland |
