new holland t8 300
 | 2011 - 2014
Model year 2011-20122013-2014
T8 SeriesRow-Crop tractor | 2011 - 2014 | Model year 2011-20122013-2014 | T8 Series | Row-Crop tractor |
|---|---|---|---|---|---|
2011 - 2014 | |||||
Model year 2011-20122013-2014 | |||||
T8 Series | |||||
Row-Crop tractor | |||||
2011 - 2014 | |
|---|---|
Model year 2011-20122013-2014 | |
T8 Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | New Holland (a part of CNH) |
Row-Crop tractor | |
Built in Racine, Wisconsin, USA | |
Variants | |
|---|---|
Magnum 260 | similar CaseIH model |
New Holland T8.300 Engine | |
|---|---|
FPT 8.7L 6-cyl diesel | |
Fuel tank | 168 gal
635.9 L |
Exhaust fluid (DEF) | 24 gal
90.8 L |
Engine details ...  | |
New Holland T8.300 Transmissions | |
|---|---|
19-speed full power shift | |
18-speed full power shift | |
23-speed creeper | |
Transmission details ...  |
New Holland T8.300 Power | |
|---|---|
Engine (gross) | 257 hp
191.6 kW |
Engine (max) | 283 hp
211.0 kW |
PTO (claimed) | 215 hp
160.3 kW |
Drawbar (tested) | 191.67 hp
142.9 kW |
PTO (tested) | 275.83 hp
205.7 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Hydraulic wet disc brakes | |
Cab standard. |
Photos | |
|---|---|
 | |
New Holland T8.300 photos...  |
Hydraulics | |
|---|---|
Type | closed center load sensing |
Rear valves | 4 to 6 |
Pump flow | 35 gpm
132.5 lpm |
Total flow | 42.5 gpm
160.9 lpm |
| 72.3 gpm*Optional MegaFlow
273.7 lpm |
Tractor hitch | |
|---|---|
Rear Type | III/IIIN |
Rear lift | 14080 lbs
6386 kg |
| 16375 lbsOptOptional
7427 kg |
Front Hitch | optional |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 1000 (1.75) |
| 540/1000 (1.375)OptOptional |
Engine RPM | 540@1804 |
| 1000@1804 |
Front PTO | independent OptOptional |
Front PTO Type | 1000 (1.375) |
Dimensions & Tires | |
|---|---|
Wheelbase | 135.8 inches
344 cm |
Weight | 23862 to 24662 pounds |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 200 |
Charging volts | 12 |
Batteries | 2 |
Battery volts | 12 |
References | |
|---|---|
 | |
T8 Series Tractors published in 2011, by New Holland | |
T8 published in 2013, by New Holland |
