steiger panther kp 1325
 | 1982 - 1985
1000 SeriesFour-wheel Drive (4WD) tractor | 1982 - 1985 | 1000 Series | Four-wheel Drive (4WD) tractor |
|---|---|---|---|---|
1982 - 1985 | ||||
1000 Series | ||||
Four-wheel Drive (4WD) tractor | ||||
1982 - 1985 | |
|---|---|
1000 Series | |
Four-wheel Drive (4WD) tractor |
Production | |
|---|---|
Manufacturer | Steiger |
Four-wheel Drive (4WD) tractor | |
Built in Fargo, North Dakota, USA | |
Original price was $125,000 in 1985 | |
Variants | |
|---|---|
CP-1325 | Caterpillar 325HP |
KP-1325 | Cummins 325HP |
CP-1360 | Caterpillar 360HP |
KP-1360 | Cummins 360HP |
CP-1400 | Caterpillar 400HP |
KP-1400 | Cummins 400HP |
Steiger Panther KP-1325 Engine | |
|---|---|
Cummins 14.0L 6-cyl diesel | |
Fuel tank | 230 gal
870.6 L |
Engine details ...  | |
Steiger Panther KP-1325 Transmission | |
|---|---|
12-speed full power shift | |
Transmission details ...  |
Steiger Panther KP-1325 Power | |
|---|---|
Engine | 325 hp
242.4 kW |
Drawbar (tested) | 264.44 hp
197.2 kW |
PTO (tested) | 301.21 hp
224.6 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Four-wheel drive | |
Final drives | outboard planetary |
Articulated power steering | |
Hydraulic disc brakes | |
Cab standard with air-conditioning. | |
Photos | |
|---|---|
 | |
Steiger Panther KP-1325 photos...  |
Hydraulics | |
|---|---|
Type | closed center |
Valves | 3 |
Tractor hitch | |
|---|---|
Rear Type | III/IV |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 141.5 inches
359 cm |
Weight | 35300 lbs
16012 kg |
Front tire | 23.1-34 |
Rear tire | 23.1-34 |
Full dimensions and tires ...  | |
Panther KP-1325 Serial Numbers | |
|---|---|
1982 | P04-00501 |
1983 | P04-02501 |
1984 | P05-03001 |
1985 | P04-05001 |
FAQ: How to read a serial number table. | |
References | |
|---|---|
 | |
The Steiger Line published in 1983 |
