steyr 9145
 | 1995 - 2003
9100 SeriesRow-Crop tractor | 1995 - 2003 | 9100 Series | Row-Crop tractor |
|---|---|---|---|---|
1995 - 2003 | ||||
9100 Series | ||||
Row-Crop tractor | ||||
1995 - 2003 | |
|---|---|
9100 Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | Steyr |
Row-Crop tractor | |
Variants | |
|---|---|
CS 150 | similar CaseIH model |
Steyr 9145 Engine | |
|---|---|
Sisu 6.6L 6-cyl diesel | |
Fuel tank | 58.1 gal
219.9 L |
| 79.3 gal*Total capacity with optional 80L fuel tank.
300.2 L |
Engine details ...  | |
Steyr 9145 Transmissions | |
|---|---|
24-speed synchronized | |
40-speed creeper | |
Transmission details ...  |
Steyr 9145 Power | |
|---|---|
Engine | 145 hp
108.1 kW |
PTO (claimed) | 128.7 hp
96.0 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Disc brakes | |
Cab standard. |
Hydraulics | |
|---|---|
Total flow | 21.1 gpm
79.9 lpm |
| 30.4 gpm
115.1 lpm |
Tractor hitch | |
|---|---|
Rear Type | III/II |
Rear lift | 19470 lbs
8831 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 (1.375) |
| 1000 (1.75)OptOptional |
Engine RPM | 540@2210 |
| 540E@1608 |
| 1000@2200 |
| 1000E@1600 |
Dimensions & Tires | |
|---|---|
Wheelbase | 110.1 inches
279 cm |
Weight | 11651 lbs
5284 kg |
Front tire | 16.9R28 |
Rear tire | 20.8R38 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Steyr 9100 published in 1995 |
