volvo 2204
 | 1979 - 1981
2200 SeriesUtility tractor | 1979 - 1981 | 2200 Series | Utility tractor |
|---|---|---|---|---|
1979 - 1981 | ||||
2200 Series | ||||
Utility tractor | ||||
1979 - 1981 | |
|---|---|
2200 Series | |
Utility tractor |
Production | |
|---|---|
Manufacturer | Volvo |
Utility tractor | |
Total built | 320 |
Variants | |
|---|---|
2200 | 2WD |
2204 | 4WD |
Volvo 2204 Engine | |
|---|---|
Volvo 3.9L 4-cyl diesel | |
Fuel tank | 23.2 gal
87.8 L |
Engine details ...  | |
Volvo 2204 Transmission | |
|---|---|
8-speed synchromesh | |
Transmission details ...  |
Volvo 2204 Power | |
|---|---|
Engine | 56 hp
41.8 kW |
PTO (claimed) | 46 hp
34.3 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Steering | hydrostatic power |
Hydraulic wet disc brakes | |
Volvo BM cab standard with heater. | |
Hydraulics | |
|---|---|
Pressure | 2495 psi
172.0 bar |
Valves | 2 |
Pump flow | 11.9 gpm
45.0 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position and draft control |
Rear lift | 4079 lbs
1850 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 (1.375) |
Engine RPM | 540@1940 |
Dimensions & Tires | |
|---|---|
Wheelbase | 85.43 inches
216 cm |
Weight | 7497 lbs
3400 kg |
Front tire | 9.5-24.8 |
Rear tire | 13.6-36.6 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 35 |
Batteries | 2 |
Battery volts | 12 |
Battery AH | 140 |
References | |
|---|---|
 | |
Volvo BM 2204 published in 1981 |
